LG 49UM5N-E Signage Display Digital signage flat panel 124.5 cm (49") LCD Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Part number 49UM5N-E
49IN 3840X2160 4K MNTR HDMI 3 DP USB 2.0 WEBOS 6
- Resolution : 3,840 x 2,160 (UHD)
- Brightness (Typ.) : 500 nit
- EPEAT (US Only)
- The carbon footprint of this product has been certified and achieved a reduction.
- Bezel Width : 12.4 mm (T/B), 11.4 mm (R/L)
- Interface : HDMI(3) / DP / USB 2.0 / RS232C / RJ45 / Audio / IR
- Manufacturer
- LG
- Part number
- 49UM5N-E
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
High Resolution Display
It offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.
Convenient webOS Platform
The UM5N-E is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.
Durability that Provides Reliability
Optimized for business environments, the UM5N-E is guarded against the potential impact of salt, dust, iron powder and humidity through the implementation of conformal coating on the power board. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and satisfaction.
Design for Space Utilization
Designed with thin bezels and simple cable management, the UM5N-E saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket.
Specifications
| Panel type | IPS |
|---|---|
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Display diagonal | 124.5 cm (49") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1100:1 |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Panel life | 50000 h |
| Colour depth | 10 bit |
| Native refresh rate | 60 Hz |
| Haze rate | 28% |
| Colour gamut | 95% |
| HDMI ports quantity | 4 |
|---|---|
| HDMI input ports quantity | 3 |
| HDMI output ports quantity | 1 |
| DVI port | No |
| DisplayPorts quantity | 1 |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232C | Yes |
| Remote (IR) input | 1 |
| Built-in speaker(s) | Yes |
|---|
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 300 x 300 mm |
| Bezel width (bottom) | 1.24 cm |
| Bezel width (side) | 1.14 cm |
| Bezel width (top) | 1.24 cm |
| Purpose | Universal |
|---|---|
| Picture-in-Picture | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Portuguese, Russian, Swedish, Turkish |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| Automatic brightness control | Yes |
| International Protection (IP) code | IP5X |
| HDCP version | 1.4/2.2 |
| Power consumption (typical) | 120 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 160 W |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 114 kWh |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Computer system | Yes |
|---|---|
| Computer system type | System on Chip (SoC) |
| Internal memory | 16 GB |
| Operating system installed | WebOS |
| Operating system version | 6.0 |
| Display width | 1102 mm |
|---|---|
| Display depth | 57.7 mm |
| Display height | 634 mm |
| Display weight | 11.4 kg |
| Package width | 1215 mm |
|---|---|
| Package depth | 152 mm |
| Package height | 736 mm |
| Package weight | 14.4 kg |
| Remote control included | Yes |
|---|---|
| Batteries included | Yes |
| Cables included | AC, Phone |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | Yes |
| Real Time Clock (RTC) | Yes |
|---|
| Audio output | 1 |
|---|---|
| Power consumption (PowerSave) | 84 W |
| Power supply type | Internal |
| Plug and Play | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
