LG 27TNF3K-S Signage Display Digital signage flat panel 68.6 cm (27") LED 300 cd/m² Full HD Silver Touchscreen WebOS 16/7
Part number 27TNF3K-S
27IN TOUCH LCD 1920X1080 MNTR WEBOS HDMI RS232 RJ45 16/7 LANDPORT
- 27" Full HD Touch Display
- Brightness : 300 nit
- Multi-Touch Point : Max. 10 Points
- Interface : HDMI (2) / RS-232C / RJ45 / IR / USB 2.0 Type A / Audio / Touch USB (USB 2.0 Type B)
- Manufacturer
- LG
- Part number
- 27TNF3K-S
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
New In-Cell Touch Open Frame for Optimal Customization
Slim & Light
The In-Cell Touch Open Frame has a touch function built into the display, allowing for the implementation of a slim design and a narrow bezel compared to general touch products that require additional touch parts (Film).
Clear Picture Quality
Compared to general touch products, 27TNF3K implements clear picture quality without milk effects caused by additional touch sensor film parts.
Design Flexibility
By providing integrated parts such as touchscreen, display, and webOS, users can realize free design for their own needs.
Wide Viewing Angle
IPS panel technology provides better control of the liquid crystals, which in turn allows the screen to be viewed at virtually any angle.
45-degree Tilt (Face up) Installation Possible
When a display is installed at low places, it is usually tilted for the user’s viewing comfort. Considering this, the installation with a max tilt of 45 degrees is supported.
10 Points of Multi-Touch
The 27TNF3K provides a more realistic touch sensation since it can recognize up to 10 points of multi-touch at once, and various touchbased user services can be provided through the screen.
High-Performance with webOS 6.0
webOS 6.0, upgraded in SoC* and web engine, is available on 27TNF3K for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI** and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.
Specifications
| Panel type | IPS |
|---|---|
| LED backlighting type | Edge-LED |
| Display diagonal | 68.6 cm (27") |
| Display technology | LED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 300 cd/m² |
| HD type | Full HD |
| Touchscreen | Yes |
| Touchscreen technology | Capacitive |
| Number of simultaneous touchpoints | 10 |
| Multi-touch | Yes |
| Native aspect ratio | 16:9 |
| Response time | 9 ms |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Colour saturation | 72% |
| Rated lifetime | 31000 h |
| Hardness | 3H |
| Native refresh rate | 60 Hz |
| HDMI ports quantity | 2 |
|---|---|
| DVI port | No |
| USB port | Yes |
| USB ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| Ethernet LAN (RJ-45) ports | 1 |
| Number of speaker outputs | 1 |
| Remote (IR) input | 1 |
| Built-in speaker(s) | No |
|---|
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor |
| Product colour | Silver |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 200 x 100 mm |
| Bezel width (bottom) | 9.7 mm |
| Bezel width (side) | 7.7 mm |
| Bezel width (top) | 7.7 mm |
| Anti-glare screen | Yes |
| Purpose | Universal |
|---|---|
| On Screen Display (OSD) | Yes |
| Operating hours (hours/days) | 16/7 |
| HDCP | Yes |
| HDCP version | 1.4 |
| Power consumption (standby) | 0.5 W |
|---|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system | Yes |
|---|---|
| Computer system type | System on Chip (SoC) |
| Internal storage capacity | 8 GB |
| Operating system installed | WebOS |
| Display width | 614.9 mm |
|---|---|
| Display depth | 15.1 mm |
| Display height | 355.3 mm |
| Display weight | 4.2 kg |
| Package width | 707 mm |
|---|---|
| Package depth | 171 mm |
| Package height | 451 mm |
| Package volume | 6200 cm³ |
| Remote control included | Yes |
|---|---|
| Cables included | AC, USB Type-A to USB Type-B |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | No |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
