Overview
Lenovo ThinkVision Interactive Large Format Display (iLFD) T86 puts you in control of every situation with an intelligent Android system environment that includes a powerful Launcher and smart tools to empower collaboration, making interaction effortless and intuitive. The Sidebars at the screen’s edge help save precious seconds by getting you instantly to the functions you need. Click the More Apps icon at the bottom of the screen to view the full menu of installed applications.
Specifications
Display
| Display diagonal | 2.18 m (86") |
|---|
| Display resolution | 3840 x 2160 pixels |
|---|
| HD type | 4K Ultra HD |
|---|
| Native aspect ratio | 16:9 |
|---|
| Display technology | LED |
|---|
| Panel type | VA |
|---|
| Backlight type | Direct LED |
|---|
| Touchscreen | Yes |
|---|
| Touchscreen technology | Infrared |
|---|
| Touch technology | Multi-touch |
|---|
| Display brightness (typical) | 400 cd/m² |
|---|
| Response time | 6.5 ms |
|---|
| Anti-glare screen | Yes |
|---|
| Screen shape | Flat |
|---|
| Contrast ratio (typical) | 4000:1 |
|---|
| Contrast ratio (dynamic) | 3000000:1 |
|---|
| Maximum refresh rate | 60 Hz |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Display number of colours | 1.07 billion colours |
|---|
| Pixel pitch | 0.4935 x 0.4935 mm |
|---|
| Pixel density | 51 ppi |
|---|
| Viewable size, horizontal | 189.5 cm |
|---|
| Viewable size, vertical | 106.6 cm |
|---|
| High Dynamic Range (HDR) supported | Yes |
|---|
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
|---|
| Colour depth | 10 bit |
|---|
| sRGB coverage (typical) | 99% |
|---|
| NTSC coverage (typical) | 85% |
|---|
Multimedia
| Number of speakers | 2 |
|---|
| RMS rated power | 15 W |
|---|
| Built-in speaker(s) | Yes |
|---|
| Built-in microphone | Yes |
|---|
| Built-in camera | No |
|---|
Design
| Market positioning | Business |
|---|
| Product colour | Black |
|---|
| Colour name | Raven black |
|---|
Ports & interfaces
| Built-in USB hub | Yes |
|---|
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
|---|
| USB upstream port type | USB Type-A, USB Type-B, USB Type-C |
|---|
| Number of upstream ports | 9 |
|---|
| Number of USB Type-B upstream ports quantity | 1 |
|---|
| Number of USB Type-C upstream ports quantity | 2 |
|---|
| USB Type-A downstream ports quantity | 5 |
|---|
| USB Touch port | Yes |
|---|
| USB Touch ports quantity | 2 |
|---|
| VGA (D-Sub) ports quantity | 1 |
|---|
| HDMI | Yes |
|---|
| HDMI ports quantity | 5 |
|---|
| HDMI version | 2.0 |
|---|
| DisplayPorts quantity | 1 |
|---|
| DisplayPort version | 1.2 |
|---|
| Audio input | Yes |
|---|
| Audio output | Yes |
|---|
| Microphone in | Yes |
|---|
| PC Audio in | Yes |
|---|
| OPS module slot | Yes |
|---|
Network
| Wi-Fi | Yes |
|---|
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
|---|
| Bluetooth | Yes |
|---|
| Bluetooth version | 5.0 |
|---|
| Ethernet LAN | Yes |
|---|
| Remotely operated | Yes |
|---|
Ergonomics
| VESA mounting | Yes |
|---|
| Panel mounting interface | 800 x 600 mm |
|---|
| Wall mountable | Yes |
|---|
| Height adjustment | No |
|---|
| On Screen Display (OSD) | Yes |
|---|
Power
| Energy efficiency class (SDR) | G |
|---|
| Energy consumption (SDR) per 1000 hours | 193 kWh |
|---|
| Power consumption (typical) | 350 W |
|---|
| Power consumption (max) | 410 W |
|---|
| Power consumption (off) | 0.5 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Power supply type | Internal |
|---|
| Energy efficiency scale | A to G |
|---|
Weight & dimensions
| Width (without stand) | 1982 mm |
|---|
| Depth (without stand) | 92 mm |
|---|
| Height (without stand) | 1209.2 mm |
|---|
| Weight (without stand) | 68 kg |
|---|
| Bezel width (side) | 1.88 cm |
|---|
Packaging data
| Package width | 2119 mm |
|---|
| Package depth | 275 mm |
|---|
| Package height | 1353 mm |
|---|
| Package weight | 88 kg |
|---|
Packaging content
| Cables included | AC, HDMI, USB Type-A to USB Type-B |
|---|
| Remote control included | Yes |
|---|
| Stylus included | Yes |
|---|
| Quick start guide | Yes |
|---|
| Remote control batteries included | Yes |
|---|
Other features
| Certification | RoHS
TÜV Rheinland Flicker Free
TÜV Rheinland Low Blue Light |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
