Overview
Make productivity portable with ThinkVision M15. Its stunning form factor is meticulously designed to expand and match the screen real estate of multiple kinds of laptop, this light and slim 15.6-inch FHD resolution mobile monitor weighs just 860g while its head measures a mere 6 mm thick, making it perfect for multi-screen multitasking like spreadsheets in an airport lounge or sharing a presentation with a prospect in a restaurant.
Equipped with two identical USB Type-C ports, the monitor gives users indispensable Power Pass Through capability. That means they can power both the monitor and the laptop with a single power adapter, plugged into one port with a USB Type-C cable connected to the computer from the other port. Or they can simply power M15 from the laptop using just one USB Type-C connection. With safety ever in ThinkVision's minds, the M15 mobile monitor also comes equipped with TÜV Rheinland certified Low Blue Light technology, which protects users from eyestrain caused by certain frequencies of blue light. Simply turn it on with the press of a button.
Specifications
Display
| Display diagonal | 39.6 cm (15.6") |
|---|
| Display resolution | 1920 x 1080 pixels |
|---|
| HD type | Full HD |
|---|
| Native aspect ratio | 16:9 |
|---|
| Display technology | LED |
|---|
| Panel type | IPS |
|---|
| Backlight type | W-LED |
|---|
| Touchscreen | No |
|---|
| Display brightness (typical) | 250 cd/m² |
|---|
| Response time | 14 ms |
|---|
| Anti-glare screen | Yes |
|---|
| Screen shape | Flat |
|---|
| Contrast ratio (typical) | 1000:1 |
|---|
| Contrast ratio (dynamic) | 3000000:1 |
|---|
| Maximum refresh rate | 60 Hz |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Display number of colours | 16.7 million colours |
|---|
| Response time (fast) | 6 ms |
|---|
| Pixel pitch | 0.1793 x 0.1793 mm |
|---|
| Viewable size, vertical | 34.4 cm |
|---|
| Viewable size diagonal | 19.4 cm |
|---|
| Colour gamut standard | NTSC |
|---|
| Colour gamut | 45% |
|---|
Design
| Product colour | Black |
|---|
Ports & interfaces
| Built-in USB hub | Yes |
|---|
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
|---|
| USB upstream port type | USB Type-C |
|---|
| Number of USB Type-C upstream ports quantity | 1 |
|---|
| USB Type-C downstream ports quantity | 1 |
|---|
| USB Type-C DisplayPort Alternate Mode | Yes |
|---|
Ergonomics
| VESA mounting | Yes |
|---|
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
| Height adjustment | Yes |
|---|
| Adjustable height (max) | 1 cm |
|---|
| Tilt adjustment | Yes |
|---|
| Tilt angle range | 0 - 90° |
|---|
| On Screen Display (OSD) | Yes |
|---|
Power
| Energy efficiency class (SDR) | C |
|---|
| Energy consumption (SDR) per 1000 hours | 8 kWh |
|---|
| Power consumption (typical) | 8 W |
|---|
| Power consumption (standby) | 0.3 W |
|---|
| Power consumption (max) | 9.5 W |
|---|
| Energy efficiency scale | A to G |
|---|
Weight & dimensions
| Width (with stand) | 360 mm |
|---|
| Depth (with stand) | 108.4 mm |
|---|
| Height (with stand) | 235.5 mm |
|---|
| Weight (with stand) | 860 g |
|---|
Packaging data
| Package width | 407.9 mm |
|---|
| Package depth | 75.9 mm |
|---|
| Package height | 279.9 mm |
|---|
| Package weight | 1.69 kg |
|---|
Other features
| Certification | ENERGY STAR
CCC
RoHS
TÜV |
|---|
