Overview
ThinkVision S24e-20 is an excellent performer that delivers core functionality with a sleek new form factor. Its 1920 x 1080 FHD resolution VA panel up to angles as extreme as 178°.The compact screen head is twice as slim as its previous generation and sits within a compact 3-side NearEdgeless frame.The stand’s built-in cable management system keeps wires out of sight and out mind. Which is a good thing because, with HDMI, VGA and Audio Out ports, S24e-20 can connect to a whole range of mission-critical devices. And because your staff are your most precious asset, S24e-20 has TÜV Rheinland Eye Comfort Certified technology to protect them from eye fatigue.
Specifications
Display
| Display diagonal | 60.5 cm (23.8") |
|---|
| Display resolution | 1920 x 1080 pixels |
|---|
| HD type | Full HD |
|---|
| Native aspect ratio | 16:9 |
|---|
| Display technology | LED |
|---|
| Panel type | VA |
|---|
| Touchscreen | No |
|---|
| Display brightness (typical) | 250 cd/m² |
|---|
| Response time | 6 ms |
|---|
| Anti-glare screen | Yes |
|---|
| Screen shape | Flat |
|---|
| Contrast ratio (typical) | 3000:1 |
|---|
| Contrast ratio (dynamic) | 3000000:1 |
|---|
| Maximum refresh rate | 60 Hz |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Display number of colours | 16.7 million colours |
|---|
| Response time (fast) | 4 ms |
|---|
| Pixel pitch | 0.2745 x 0.2745 mm |
|---|
| Pixel density | 93 ppi |
|---|
| Viewable size, horizontal | 52.7 cm |
|---|
| Viewable size, vertical | 29.6 cm |
|---|
| Colour gamut standard | NTSC |
|---|
| NTSC coverage (typical) | 72% |
|---|
Performance
| NVIDIA G-SYNC | No |
|---|
| AMD FreeSync | Yes |
|---|
| AMD FreeSync type | FreeSync |
|---|
Multimedia
| Built-in speaker(s) | No |
|---|
| Built-in camera | No |
|---|
Design
| Market positioning | Home |
|---|
| Product colour | Black |
|---|
| Colour name | Raven Black |
|---|
Ports & interfaces
| Built-in USB hub | No |
|---|
| VGA (D-Sub) ports quantity | 1 |
|---|
| DVI port | No |
|---|
| HDMI | Yes |
|---|
| HDMI ports quantity | 1 |
|---|
| HDMI version | 1.4 |
|---|
| Audio input | No |
|---|
| Audio output | Yes |
|---|
| Headphone out | No |
|---|
Ergonomics
| VESA mounting | Yes |
|---|
| Panel mounting interface | 100 x 100 mm |
|---|
| Cable management | Yes |
|---|
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
| Tilt adjustment | Yes |
|---|
| Tilt angle range | -5 - 22° |
|---|
| On Screen Display (OSD) | Yes |
|---|
Power
| Power consumption (typical) | 17.5 W |
|---|
| Power consumption (standby) | 0.5 W |
|---|
| Power consumption (max) | 23.5 W |
|---|
| Power consumption (off) | 0.5 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Power supply type | Internal |
|---|
Weight & dimensions
| Width (with stand) | 540.4 mm |
|---|
| Depth (with stand) | 173.1 mm |
|---|
| Height (with stand) | 434.5 mm |
|---|
| Weight (with stand) | 3.82 kg |
|---|
| Width (without stand) | 540.4 mm |
|---|
| Depth (without stand) | 45.5 mm |
|---|
| Height (without stand) | 327.2 mm |
|---|
| Weight (without stand) | 3.02 kg |
|---|
| Bezel width (side) | 2.5 mm |
|---|
| Bezel width (top) | 2.5 mm |
|---|
| Bezel width (bottom) | 2.24 cm |
|---|
Packaging data
| Package width | 624 mm |
|---|
| Package depth | 415 mm |
|---|
| Package height | 124 mm |
|---|
| Package weight | 5.42 kg |
|---|
Packaging content
| Stand included | Yes |
|---|
| Cables included | HDMI |
|---|
