Lenovo ThinkStation P3 Tower Gen 2 Intel Core Ultra 9 285 32 GB DDR5-SDRAM 1 TB SSD NVIDIA RTX PRO 5000 Blackwell Windows 11 Pro Workstation
Part number 30HT0075US
THINKSTATION P3 TOWER G2 ICORE ULTRA 9 285 VPRO 4.60GHZ 36MB
- Intel Core Ultra 9 285, 24C (8P + 16E)/24T, Max Turbo up to 5.6GHz, 36MB Intel Smart Cache
- 2x 16GB UDIMM DDR5-5600 Non-ECC
- 1x 1TB SSD M.2 2280 PCIe 5.0x4 NVMe Opal
- 1x NVIDIA RTX PRO 5000 Blackwell 48GB GDDR7
- Windows 11 Pro
- Manufacturer
- Lenovo
- Part number
- 30HT0075US
- Condition
- New
- Category
- Computer Systems › Workstations
- 1GPA category
- Hardware
Overview
Workstation might, desktop price
Designed by engineers for engineers, the Lenovo ThinkStation P3 Tower offers all the workhorse capabilities of a workstation for the price of a desktop. Built for tasks that require superior power and performance, it's equipped with Intel® Core™ processors with Intel vPro®, and supports professional NVIDIA® discrete graphics.
Delivering power & performance
The ThinkStation P3 Tower’s chassis has an advanced thermal design to promote extra power and performance, without overheating. It also comes with a choice of operating systems, including Windows 11 Pro and Linux®. In short, the P3 gives you the compute power to execute your visions, time and time again.
Configure it any which way
With three onboard DisplayPorts, plus the ability to configure up to eight more, the ThinkStation P3 Tower can support up to 12 independent displays. It also comes with a choice of operating systems, including Windows 11 Pro and Red Hat® Enterprise Linux®. And with heaps of speedy memory and SSD storage, plus five open PCIe slots, this workstation can be configured to tackle your most exacting workflows. It also comes with a USB mouse and keyboard.
Mission-critical performance, made easy
At the heart of every Lenovo ThinkStation is reliability. Proven to run in extreme conditions, the ThinkStation P3 Tower also boasts an array of independent software vendor (ISV) certifications. It's the perfect workstation for designers, engineers, and students looking for versatility, flexibility, and breakthrough performance to breeze through heavy workloads.
See the complete list of ISV certifications.
Security you can count on
The ThinkStation P3 Tower is protected with ThinkShield, a suite of hardware and software that work together to safeguard your workstation and data. This includes the discrete Trusted Platform Module (TPM) 2.0 to encrypt sensitive data, as well as various programs to prevent unauthorized access to the BIOS, plus self-healing software if the BIOS is corrupted or maliciously attacked. For extra peace of mind, it also supports Windows firmware updates.
Specifications may vary depending upon region / model.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel Core Ultra 9 |
| Processor model | 285 |
| Processor cores | 24 |
| Processor threads | 24 |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 256 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 5600 MHz |
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | DVD±RW |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 5.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Self-Encrypting Drive (SED) | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Discrete graphics card | Yes |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card model | NVIDIA RTX PRO 5000 Blackwell |
| Discrete graphics card memory | 48 GB |
| Discrete graphics memory type | GDDR7 |
| Number of discrete graphics cards | 1 |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card model | Intel® Graphics |
| Motherboard chipset | Intel W880 |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Product type | Workstation |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| WLAN controller manufacturer | Intel |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| DisplayPorts quantity | 3 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Microphone in | Yes |
| Power supply | 750 W |
|---|
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Operating system installed | Windows 11 Pro |
|---|
| Intel® Smart Cache | Yes |
|---|
| Audio chip | Realtek ALC623 |
|---|---|
| Audio system | High Definition Audio |
| Width | 180 mm |
|---|---|
| Depth | 370 mm |
| Height | 415 mm |
| Weight | 14.4 kg |
| Mouse included | Yes |
|---|---|
| Mouse connectivity | Wired |
| Keyboard included | Yes |
| Keyboard connectivity | Wired |
|---|
