Lenovo
Lenovo ThinkStation P3 Tower Intel® Core™ i5 i5-14500 32 GB DDR5-SDRAM 1 TB SSD Windows 11 Pro Workstation
Part number 30GS00E6US
THREE YEAR PREMIER
- Intel Core i5-14500, 14C (6P + 8E)/20T, P-core 2.6/5.0GHz, E-core 1.9/3.7GHz, 24MB Intel Smart Cache
- 1x 32GB UDIMM DDR5-4400 Non-ECC
- 1x 1TB SSD M.2 2280 PCIe 4.0x4 NVMe Opal
- Intel UHD Graphics 770
- Windows 11 Pro
- Manufacturer
- Lenovo
- Part number
- 30GS00E6US
- Condition
- New
- Category
- Computer Systems › Workstations
- 1GPA category
- Hardware
Specifications
Processor
| Processor manufacturer | Intel |
|---|
| Processor family | Intel® Core™ i5 |
|---|
| Processor model | i5-14500 |
|---|
| Processor cores | 14 |
|---|
| Processor threads | 20 |
|---|
| Processor boost frequency | 5 GHz |
|---|
| Processor frequency | 2.6 GHz |
|---|
Memory
| Internal memory | 32 GB |
|---|
| Maximum internal memory | 128 GB |
|---|
| Internal memory type | DDR5-SDRAM |
|---|
| Memory layout (slots x size) | 1 x 32 GB |
|---|
| Memory slots | 4x DIMM |
|---|
| Memory clock speed | 4400 MHz |
|---|
Storage
| Total storage capacity | 1 TB |
|---|
| Storage media | SSD |
|---|
| Optical drive type | No |
|---|
| Total SSDs capacity | 1 TB |
|---|
| Number of SSDs installed | 1 |
|---|
| SSD capacity | 1 TB |
|---|
| SSD interface | PCI Express 4.0 |
|---|
| NVMe | Yes |
|---|
| SSD form factor | M.2 |
|---|
| Card reader integrated | Yes |
|---|
| Compatible memory cards | SD |
|---|
Graphics
| Discrete graphics card | No |
|---|
| On-board graphics card | Yes |
|---|
| Discrete graphics card model | Not available |
|---|
| On-board GPU manufacturer | Intel |
|---|
| On-board graphics card family | Intel® UHD Graphics |
|---|
| On-board graphics card model | Intel UHD Graphics 770 |
|---|
Performance
| Motherboard chipset | Intel W680 |
|---|
| Trusted Platform Module (TPM) | Yes |
|---|
| Product type | Workstation |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
|---|
| Wi-Fi | Yes |
|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
|---|
| WLAN controller manufacturer | Intel |
|---|
| WLAN controller model | Intel Wi-Fi 6E AX211 |
|---|
| Antenna type | 2x2 |
|---|
| Bluetooth | Yes |
|---|
| Bluetooth version | 5.3 |
|---|
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
|---|
| DisplayPorts quantity | 3 |
|---|
| HDMI ports quantity | 1 |
|---|
| HDMI version | 2.1 |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Combo headphone/mic port | Yes |
|---|
| Line-out | Yes |
|---|
| Microphone in | Yes |
|---|
Design
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
Software
| Operating system language | English |
|---|
| Operating system installed | Windows 11 Pro |
|---|
Audio
| Audio chip | Realtek ALC897Q-CG |
|---|
| Audio system | High Definition Audio |
|---|
Weight & dimensions
| Width | 180 mm |
|---|
| Depth | 370 mm |
|---|
| Height | 415 mm |
|---|
| Weight | 13.6 kg |
|---|
Packaging content
| Mouse included | Yes |
|---|
| Mouse connectivity | Wired |
|---|
| Keyboard included | Yes |
|---|
Keyboard
| Keyboard connectivity | Wired |
|---|
