Lenovo
Lenovo ThinkStation P5 Intel® Xeon® 32 GB DDR5-SDRAM 512 GB SSD Windows 10 Pro for Workstations Workstation
Part number 30GA00B1US
THINKSTATION P5 W32435 16G X2 W 11PWS
- Intel Xeon w3-2435, 8C (8P + 0E)/16T, 3.1/4.5GHz, 22.5MB
- 2x 16GB RDIMM DDR5-4800 ECC
- 1x 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal
- 1x NVIDIA RTX PRO 2000 Blackwell 16GB GDDR7
- Windows 11 Pro for Workstations
- Manufacturer
- Lenovo
- Part number
- 30GA00B1US
- Condition
- New
- Category
- Computer Systems › Workstations
- 1GPA category
- Hardware
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Xeon® |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 4.5 GHz |
| Processor frequency | 3.1 GHz |
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 512 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 8x DIMM |
| Memory clock speed | 4800 MHz |
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Discrete graphics card | Yes |
|---|---|
| Discrete graphics card memory | 16 GB |
| Discrete graphics memory type | GDDR7 |
| Number of discrete graphics cards | 1 |
| Motherboard chipset | Intel W790 |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Product type | Workstation |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Power supply | 1000 W |
|---|
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Operating system language | English |
|---|---|
| Operating system installed | Windows 10 Pro for Workstations |
| Audio chip | Realtek ALC897-Q |
|---|---|
| Audio system | High Definition Audio |
| Width | 165 mm |
|---|---|
| Depth | 453.9 mm |
| Height | 440 mm |
| Weight | 19 kg |
| Mouse included | Yes |
|---|---|
| Mouse connectivity | Wired |
| Keyboard included | Yes |
| Keyboard connectivity | Wired |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
