Lenovo ThinkStation P5 Intel Xeon W w7-2495X 64 GB DDR5-SDRAM 2 TB SSD NVIDIA RTX A5500 Windows 11 Pro for Workstations Tower Workstation Black, Red
Part number 30GA004GUS
THINKSTATION P5 XEON W7-2495X 2.5G 64GB 2TB SSD W11P
- Up to one Intel® Xeon® w7-2495X with 24 cores
- Up to Windows® 11 Pro for Workstations
- Supports up to two NVIDIA® RTX 5000 Ada Generation or two NVIDIA® RTX A6000
- Up to 512GB, 8 DDR5 DIMM slots
- Up to 10 drives (3x 3.5" SATA HDD + 7x M.2 SSD)
- Manufacturer
- Lenovo
- Part number
- 30GA004GUS
- Condition
- New
- Category
- Computer Systems › Workstations
- 1GPA category
- Hardware
Overview
ThinkStation P5
Powered for modern businesses, the brand-new ThinkStation P5 features dependable power, performance and security at its best. The up to 1 Intel Xeon W-2400 series processor supports up to 24 cores and delivers top-notch productivity in any workspace. Its HD Realtek audio and 1.5W speaker
bring massive, detailed soundstage that takes online streaming and conferencing to the next level. Security features, including the Discrete TPM 2.0 chip, Kensington security slot and chassis intrusion switch provide end-to-end protection against device and data theft.
Whether working from remote job locations or a corporate space, the Intel Wi-Fi 6E feature enables consistent speed and strong bandwidth at all times. The front and rear connectivity ports, including USB-C 3.2 Gen 2 allow seamless data transfer and connectivity to monitors and peripherals.
With up to 512GB DDR5 memory support and up to 4TB storage, this workstation lets users multitask and switch between applications without having to worry about performance and speed.
It has up to 512 DDR5 GB memory, supports up NVIDIA RTX A6000 graphics, up to 1 Intel Xeon processor as well as up to 4TB SSD storage, which make it a powerful workstation that breezes through compute-intensive tasks or heavy-duty applications easily.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel Xeon W |
| Processor model | w7-2495X |
| Processor cores | 24 |
| Processor threads | 48 |
| Processor boost frequency | 4.8 GHz |
| Processor frequency | 2.5 GHz |
| Performance cores | 24 |
| Processor cache | 45 MB |
| Processor cache type | Smart Cache |
| PCI Express slots version | 4.0, 5.0 |
| Processor socket | LGA 4677 (Socket E) |
| Processor base power | 225 W |
| Maximum turbo power | 270 W |
| Internal memory | 64 GB |
|---|---|
| Maximum internal memory | 512 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 4 x 16 GB |
| Memory slots | 8x DIMM |
| Memory clock speed | 4800 MHz |
| ECC | Yes |
| Non-ECC | No |
| Memory channels | Quad-channel |
| Total storage capacity | 2 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 2 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 2 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Card reader integrated | Yes |
| Discrete graphics card | Yes |
|---|---|
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA RTX A5500 |
| Discrete graphics card memory | 24 GB |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
| Motherboard chipset | Intel W790 |
|---|---|
| Password protection | Yes |
| Password protection type | Power on, Supervisor |
| BIOS type | UEFI |
| Trusted Platform Module (TPM) | Yes |
| Product type | Workstation |
| Trusted Platform Module (TPM) version | 2.0 |
| Built-in speaker(s) | Yes |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Intel® I219-LM |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | 802.11ad, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| Wake-on-LAN ready | Yes |
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Power supply | 1000 W |
|---|---|
| 80 PLUS certification | 80 PLUS Platinum |
| Chassis type | Tower |
|---|---|
| Volume | 33 L |
| Placement supported | Vertical |
| Product colour | Black, Red |
| Operating system architecture | 64-bit |
|---|---|
| Operating system language | English |
| Operating system installed | Windows 11 Pro for Workstations |
| Intel® Turbo Boost Max Technology 3.0 frequency | 4.8 GHz |
|---|---|
| Intel® Turbo Boost Technology | 3.0 |
| Display included | No |
|---|
| Audio chip | Realtek ALC897-Q |
|---|---|
| Audio system | High Definition Audio |
| Number of speakers | 1 |
| Operating temperature (T-T) | 10 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Width | 165 mm |
|---|---|
| Depth | 453.9 mm |
| Height | 446 mm |
| Weight | 24.5 kg |
| Mouse included | Yes |
|---|---|
| Mouse connectivity | Wired |
| Keyboard included | Yes |
| Compliance certificates | RoHS |
|---|---|
| Certification | TCG certified, FIPS 140-2 certified, TCO Certified 9.0 |
| Sustainability certificates | ENERGY STAR, EPEAT Gold, TCO |
|---|
| Keyboard connectivity | Wired |
|---|---|
| Keyboard layout | QWERTY |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
