Lenovo ThinkStation P620 AMD Ryzen Threadripper PRO 3945WX 32 GB DDR4-SDRAM 1 TB SSD NVIDIA Quadro T1000 Windows 10 Pro Tower Workstation Black
Part number 30E000DQUS
WORKSTATION TS P620 3945WX 16G W10P
- Workstation Black 1000 W
- AMD Ryzen Threadripper PRO 3945WX 4 GHz Processor cores: 12
- 32 GB DDR4-SDRAM 3200 MHz 2 x 16 GB
- 1 TB SSD Card reader integrated
- NVIDIA Quadro T1000 4 GB
- Ethernet LAN 10,100,1000,2500,5000,10000 Mbit/s
- Windows 10 Pro 64-bit
- Manufacturer
- Lenovo
- Part number
- 30E000DQUS
- Condition
- New
- Category
- Computer Systems › Workstations
- 1GPA category
- Hardware
Overview
Limitless possibilities. Game-changing power.
Reliability & speed.
Meet the ThinkStation P620
Imagine your business being able to visualize, compute, and create on a system that delivers unparalleled ROI.
Lenovo has partnered with AMD to create the world’s first and only AMD Threadripper™ Pro workstation—delivering a dual-CPU experience in a single-processor system that is performance-tuned and ISV certified for multithreaded application environments.
Power like you’ve never experienced
Backed by enterprise-level features for seamless security, manageability, and support.
Uncompromised performance. Legendary reliability. Robust usability.
Cost-effective alternative to dual-socket systems
Media & Entertainment: Whether used for 3D animation, compositing, editing, creative finishing, or rendering, the ThinkStation P620 delivers high clock speed and 12, 16, 32 and 64-core AMD Threadripper™ Pro processors so you can realize your creative vision.
Specifications
| Processor manufacturer | AMD |
|---|---|
| Processor family | AMD Ryzen Threadripper PRO |
| Processor generation | AMD Ryzen Threadripper PRO 3000 WX-Series |
| Processor model | 3945WX |
| Processor cores | 12 |
| Processor threads | 24 |
| Processor boost frequency | 4.3 GHz |
| Processor frequency | 4 GHz |
| Processor cache | 64 MB |
| Processor cache type | L2 & L3 |
| Number of processors installed | 1 |
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 1 TB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 8x DIMM |
| Memory clock speed | 3200 MHz |
| ECC | Yes |
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | NVMe, PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Discrete graphics card | Yes |
|---|---|
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA Quadro T1000 |
| Discrete graphics card memory | 4 GB |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
| Motherboard chipset | AMD WRX80 |
|---|---|
| Password protection | Yes |
| Password protection type | Power on, Supervisor |
| Trusted Platform Module (TPM) | Yes |
| Product type | Workstation |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 10,100,1000,2500,5000,10000 Mbit/s |
| LAN controller | Marvell AQtion AQN-107 |
| Wi-Fi | No |
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| DVI port | No |
| PS/2 ports quantity | 2 |
| PCI Express x8 slots | 2 |
|---|---|
| PCI Express x16 (Gen 4.x) slots | 4 |
| Power supply | 1000 W |
|---|---|
| 80 PLUS certification | 80 PLUS Platinum |
| Chassis type | Tower |
|---|---|
| Volume | 33 L |
| Placement supported | Vertical |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Operating system architecture | 64-bit |
|---|---|
| Operating system language | English |
| Operating system installed | Windows 10 Pro |
| Display included | No |
|---|
| Audio chip | Realtek ALC4050H |
|---|---|
| Audio system | High Definition Audio |
| Operating temperature (T-T) | 10 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Width | 165 mm |
|---|---|
| Depth | 460 mm |
| Height | 446 mm |
| Weight | 24 kg |
| Mouse included | Yes |
|---|---|
| Keyboard included | Yes |
| Compliance certificates | RoHS |
|---|
| Sustainability certificates | ENERGY STAR, EPEAT Silver, GREENGUARD |
|---|
| Keyboard layout | QWERTY |
|---|
