Lenovo ThinkStation P520c Intel Xeon W W-2225 16 GB DDR4-SDRAM 512 GB SSD NVIDIA RTX A4500 Windows 11 Pro for Workstations Tower Workstation Black
Part number 30BX00J0US
TOPSELLER TS P520C XEON W-2225 4.10G 16GB 512GB SSD W11P
- Windows 11 Pro for Workstations 64-bit
- Intel Xeon W-2225 (8.25MB Cache, 4.1GHz)
- NVIDIA RTX A4500 (20GB GDDR6)
- 16GB DDR4-SDRAM & 512GB SSD
- Manufacturer
- Lenovo
- Part number
- 30BX00J0US
- Condition
- New
- Category
- Computer Systems › Workstations
- 1GPA category
- Hardware
Overview
High-level performance without the high price
From large workloads to multitasking, the compact ThinkStation P520c breezes through it all. With cutting-edge processing, graphics, storage, and memory, this configurable 25L workstation is a solid workhorse. Energy efficient and extremely reliable, it's also ISV-certified and VR-ready. Equally impressive is the affordable price tag.
Real power at a reasonable price
For true processing power and blazing-fast visuals, power up the ThinkStation P520c. Fueled by the latest Intel® Xeon® processors and NVIDIA® Quadro® graphics, this compact 25L workhorse can help you to get the job done, quickly and easily. What's more, it comes at a very affordable price.
Configurable and reliable
The P520c can be configured to meet your specific needs, including up to 128 GB of memory and solid-state or hard disk drive storage options. One thing you won't have to worry about, however, is reliability, which is the cornerstone of every ThinkStation.
Enhanced flexible design
With two M.2 PCIe solid state drive slots embedded in the motherboard, you can enjoy blistering-fast storage speeds. What's more, the front FLEX module gives you a range of options and flexibility, including a media card reader and blazing-fast Intel® Thunderbolt™ 3 port.
Hassle-free, tool-free
Should you ever need to swap any components, there’s no need to worry about tools. Simply slide off the side panel and away you go. You may also wish to know that we can help automate many of the manual tasks associated with deploying new machines, from asset tagging to custom image loading.
Ready for anything, real or virtual
With virtual reality (VR), almost anything's possible—from revolutionary designs to stunning special effects to highly complex simulations. With the powerful P520c and top-of-the range, high-performance NVIDIA Quadro® graphics (optional), a truly immersive VR experience awaits.
Built-in peace of mind
Like every ThinkStation before it, the P520c has undergone rigorous testing under extreme conditions. It's also ISV-certified and boasts error-correcting code (ECC) memory, ensuring even greater accuracy and reliability.
A helping hand when you need it
You’ll be able to keep your P520c running at its peak thanks to Lenovo Workstation Diagnostics. Available for both desktop and smartphone, this intelligent app can help you diagnose and troubleshoot potential system issues by providing step-by-step guidance on optimal system performance. And should your machine ever fail to boot, an error code for additional assistance will be sent wirelessly to your smartphone.
In addition, there's Lenovo Performance Tuner. Free to download and easy to use, this software can help you fine-tune your workstation to get even more out of it.
Better for the planet—and your bottom line
The P520c meets some of the world's most comprehensive environmental standards. A GREENGUARD®-certified workstation, it has also been rated EPEAT Gold, ENERGY STAR 6.1, and up to 80 PLUS® Platinum PSU. And as a result of its energy efficiency, the P520c can even help lower your utility bills.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel Xeon W |
| Processor model | W-2225 |
| Processor cores | 4 |
| Processor boost frequency | 4.6 GHz |
| Processor frequency | 4.1 GHz |
| Processor cache | 8.25 MB |
| Number of processors installed | 1 |
| Internal memory | 16 GB |
|---|---|
| Internal memory type | DDR4-SDRAM |
| Memory slots | 4x DIMM |
| ECC | Yes |
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 3.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Discrete graphics card | Yes |
|---|---|
| Discrete graphics card model | NVIDIA RTX A4500 |
| Discrete graphics card memory | 20 GB |
| Discrete graphics memory type | GDDR6 |
| Number of discrete graphics cards | 1 |
| Graphics card DisplayPorts quantity | 4 |
| Motherboard chipset | Intel® C422 |
|---|---|
| Password protection | Yes |
| Password protection type | Power on |
| Trusted Platform Module (TPM) | Yes |
| Product type | Workstation |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | No |
| Bluetooth | No |
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| DVI port | No |
| PS/2 ports quantity | 2 |
| Power supply | 625 W |
|---|---|
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
| Chassis type | Tower |
|---|---|
| Volume | 25 L |
| Product colour | Black |
| Operating system architecture | 64-bit |
|---|---|
| Operating system language | English |
| Operating system installed | Windows 11 Pro for Workstations |
| CPU configuration (max) | 1 |
|---|
| Audio chip | Realtek ALC662 |
|---|---|
| Audio system | High Definition Audio |
| Operating temperature (T-T) | 10 - 35 °C |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Operating altitude | -15.2 - 3048 m |
| Width | 175 mm |
|---|---|
| Depth | 426 mm |
| Height | 376 mm |
| Weight | 14.5 kg |
| Mouse included | Yes |
|---|---|
| Keyboard included | Yes |
