Overview
Advanced dual-processor workstation
Enjoy extreme performance from this true workhorse. Powered by up to two Intel® Xeon® processors and three NVIDIA® professional GPUs, the ThinkStation P920 has the most I/O in the industry. Perfect for running intensive apps for rendering, simulation, visualization, deep learning, or artificial intelligence—whatever your industry.
Specifications
Processor
| Processor manufacturer | Intel |
|---|
| Processor family | Intel® Xeon® Gold |
|---|
| Processor model | 6258R |
|---|
| Processor cores | 28 |
|---|
| Processor boost frequency | 4 GHz |
|---|
| Processor frequency | 2.7 GHz |
|---|
| Processor cache | 38.5 MB |
|---|
| Number of processors installed | 2 |
|---|
Memory
| Internal memory | 384 GB |
|---|
| Maximum internal memory | 1 TB |
|---|
| Internal memory type | DDR4-SDRAM |
|---|
| Memory layout (slots x size) | 12 x 32 GB |
|---|
| Memory slots | 16x DIMM |
|---|
| Memory clock speed | 2933 MHz |
|---|
| ECC | Yes |
|---|
| Memory channels | Dodeca-channel |
|---|
Storage
| Total storage capacity | 3 TB |
|---|
| Storage media | HDD+SSD |
|---|
| Optical drive type | No |
|---|
| Number of storage drives installed | 2 |
|---|
| Total HDDs capacity | 2 TB |
|---|
| Number of HDDs installed | 1 |
|---|
| HDD capacity | 2 TB |
|---|
| Total SSDs capacity | 1 TB |
|---|
| Number of SSDs installed | 1 |
|---|
| SSD capacity | 1 TB |
|---|
| Card reader integrated | Yes |
|---|
Graphics
| Discrete graphics card | Yes |
|---|
| Discrete graphics card model | NVIDIA RTX A5000 |
|---|
| Discrete graphics card memory | 24 GB |
|---|
| Discrete graphics memory type | GDDR6 |
|---|
| Number of discrete graphics cards | 2 |
|---|
Performance
| Motherboard chipset | Intel® C621 |
|---|
| Password protection | Yes |
|---|
| Password protection type | Power on, Supervisor |
|---|
| BIOS type | UEFI |
|---|
| Trusted Platform Module (TPM) | Yes |
|---|
| Product type | Workstation |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
|---|
| Cabling technology | 10/100/1000Base-T(X) |
|---|
| Wi-Fi | No |
|---|
| Bluetooth | No |
|---|
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
|---|
| Ethernet LAN (RJ-45) ports | 2 |
|---|
| Combo headphone/mic port | Yes |
|---|
| Headphone outputs | 1 |
|---|
| Line-out | Yes |
|---|
| Line-in | Yes |
|---|
| Microphone in | Yes |
|---|
| DVI port | No |
|---|
| PS/2 ports quantity | 2 |
|---|
Power
| Power supply | 1400 W |
|---|
| 80 PLUS certification | 80 PLUS Platinum |
|---|
Design
| Chassis type | Tower |
|---|
| Volume | 55 L |
|---|
| Placement supported | Vertical |
|---|
| Product colour | Black |
|---|
Software
| Operating system installed | Ubuntu Linux |
|---|
Processor special features
| Intel 64 | Yes |
|---|
| Enhanced Intel SpeedStep Technology | Yes |
|---|
| Embedded options available | No |
|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
|---|
| Intel Trusted Execution Technology | Yes |
|---|
| Execute Disable Bit | Yes |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
|---|
| Intel Virtualization Technology (VT-x) | Yes |
|---|
Display
| Display included | No |
|---|
Audio
| Audio chip | Realtek ALC662 |
|---|
| Audio system | High Definition Audio |
|---|
Operational conditions
| Operating temperature (T-T) | 10 - 35 °C |
|---|
| Storage temperature (T-T) | -40 - 60 °C |
|---|
| Operating relative humidity (H-H) | 20 - 80% |
|---|
| Storage relative humidity (H-H) | 10 - 90% |
|---|
| Operating altitude | 0 - 3048 m |
|---|
| Non-operating altitude | 0 - 12192 m |
|---|
Weight & dimensions
| Width | 200 mm |
|---|
| Depth | 620 mm |
|---|
| Height | 446 mm |
|---|
| Weight | 37 kg |
|---|
Packaging content
| Mouse included | Yes |
|---|
| Keyboard included | Yes |
|---|
Certificates
| Certification | EPEAT Silver
ISV
GREENGUARD
RoHS |
|---|
