Overview
Affordable Power\nClosing the gap between price and performance, the ThinkStation® P410 offers an Intel® Xeon® E5-1600 v4 Series Processor and higher memory capacity than any competing workstation on the market. It's a mainstream workstation at an entry-level price. \n \nReliable Performer\nThe P410 is a solid, worry-free performer that can handle even the most daunting workload. Intel® Xeon® processors with Turbo Max 3.0 and NVIDIA® Quadro® graphics deliver powerful performance with ISV certifications, fully customizable storage, memory, power and I/O configurations. \n\nUnmatched Usability\nLenovo is a leader in workstation technology, engineering the systems that cater to the needs of power-hungry professionals.. ThinkStation P Series workstations don't just stop at hardware innovation, but offer the Lenovo Performance Tuner to fine-tune the user experience; including resource affinity and software-specific profiles. \n\nInnovative Features \nThe Flex module allows for unprecedented flexibility in customizing I/O ports including the fastest connection using Intel® ThunderboltTM 3.\n\nNo-hassle Deployment\nAdvanced Deployment Services include custom image load and creation, and asset tagging to protect your investment. Includes Lenovo Services for Enterprise Business Class Support.
Specifications
Processor
| Processor manufacturer | Intel |
|---|
| Processor family | Intel® Xeon® E5 v4 |
|---|
| Processor model | E5-1630V4 |
|---|
| Processor cores | 4 |
|---|
| Processor threads | 8 |
|---|
| Processor boost frequency | 4 GHz |
|---|
| Processor frequency | 3.7 GHz |
|---|
| Processor cache | 10 MB |
|---|
| Processor cache type | Smart Cache |
|---|
| Bus type | QPI |
|---|
| Processor lithography | 14 nm |
|---|
| Processor operating modes | 64-bit |
|---|
| Processor series | Intel Xeon E5-1600 v4 |
|---|
| Processor codename | Broadwell |
|---|
| Thermal Design Power (TDP) | 140 W |
|---|
| Tcase | 69 °C |
|---|
| PCI Express slots version | 3.0 |
|---|
| Maximum number of PCI Express lanes | 40 |
|---|
| PCI Express configurations | 1x16, 1x4, 1x8 |
|---|
| Number of processors installed | 1 |
|---|
| Processor socket | LGA 2011-v3 |
|---|
| Stepping | R0 |
|---|
| Maximum internal memory supported by processor | 1.53 TB |
|---|
| Memory types supported by processor | DDR4-SDRAM |
|---|
| Memory clock speeds supported by processor | 1600,1866,2133,2400 MHz |
|---|
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
|---|
| ECC supported by processor | Yes |
Memory
| Internal memory | 16 GB |
|---|
| Maximum internal memory | 128 GB |
|---|
| Internal memory type | DDR4-SDRAM |
|---|
| Memory slots | 4x DIMM |
|---|
| Memory clock speed | 2400 MHz |
|---|
| Memory channels | Quad-channel |
Storage
| Total storage capacity | 256 GB |
|---|
| Storage media | SSD |
|---|
| Optical drive type | DVD±RW |
|---|
| Number of storage drives installed | 1 |
|---|
| Number of SSDs installed | 1 |
|---|
| SSD capacity | 256 GB |
|---|
| Card reader integrated | Yes |
|---|
| Compatible memory cards | HC MMC+, MS PRO Duo Mark 2 |
|---|
| RAID support | Yes |
Graphics
| Discrete graphics card | Yes |
|---|
| On-board graphics card | No |
|---|
| Discrete graphics card model | NVIDIA® Quadro® P2000 |
|---|
| Discrete graphics card memory | 5 GB |
|---|
| Number of discrete graphics cards | 1 |
|---|
| On-board graphics card model | Not available |
Performance
| Motherboard chipset | Intel® C612 |
|---|
| Product type | Workstation |
Optical drive
| Optical drives quantity | 1 |
Network
| Ethernet LAN | Yes |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
|---|
| Cabling technology | 10/100/1000Base-T(X) |
|---|
| Wi-Fi | No |
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Headphone outputs | 1 |
|---|
| Line-out | Yes |
|---|
| Line-in | Yes |
|---|
| Microphone in | Yes |
|---|
| DVI port | No |
Design
| Chassis type | Tower |
|---|
| Placement supported | Vertical |
|---|
| Product colour | Black |
Software
| Operating system architecture | 64-bit |
|---|
| Operating system installed | Windows 7 Professional |
|---|
| Optional operating system supplied | Windows 10 Pro |
Processor special features
| Intel 64 | Yes |
|---|
| Enhanced Intel SpeedStep Technology | Yes |
|---|
| Embedded options available | No |
|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
|---|
| Intel TSX-NI | Yes |
|---|
| Idle States | Yes |
|---|
| Thermal Monitoring Technologies | Yes |
|---|
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
|---|
| Intel® Secure Key | Yes |
|---|
| Intel® OS Guard | Yes |
|---|
| Intel Trusted Execution Technology | Yes |
|---|
| Execute Disable Bit | Yes |
|---|
| Intel HD Graphics | No |
|---|
| Intel Flex Memory Access | No |
|---|
| Intel® Smart Cache | No |
|---|
| Intel Enhanced Halt State | Yes |
|---|
| Intel Demand Based Switching | Yes |
|---|
| Processor package size | 45 x 52.5 mm |
|---|
| Supported instruction sets | AVX 2.0 |
|---|
| Processor code | SR2PF |
|---|
| Scalability | 1S |
|---|
| Physical Address Extension (PAE) | Yes |
|---|
| Physical Address Extension (PAE) | 46 bit |
|---|
| CPU configuration (max) | 1 |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
|---|
| Intel Identity Protection Technology version | 1.00 |
|---|
| Intel Secure Key Technology version | 1.00 |
|---|
| Intel Virtualization Technology (VT-x) | Yes |
|---|
| Intel TSX-NI version | 1.00 |
|---|
| Processor ARK ID | 92987 |
Display
| Display included | No |
Operational conditions
| Operating temperature (T-T) | 10 - 35 °C |
|---|
| Storage temperature (T-T) | -10 - 60 °C |
|---|
| Operating relative humidity (H-H) | 10 - 80% |
|---|
| Storage relative humidity (H-H) | 10 - 90% |
|---|
| Operating altitude | 0 - 3048 m |
Weight & dimensions
| Width | 175 mm |
|---|
| Depth | 426 mm |
|---|
| Height | 376 mm |
|---|
| Weight | 14 kg |
Packaging content
| Mouse included | Yes |
|---|
| Keyboard included | Yes |
Certificates
| Compliance certificates | RoHS |
Sustainability
| Sustainability certificates | EPEAT Gold, ENERGY STAR |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
