Lenovo
Lenovo ThinkPad P1 Gen 7 Intel Core Ultra 5 135H Mobile workstation 40.6 cm (16") WUXGA 16 GB LPDDR5x-SDRAM 512 GB SSD Wi-Fi 7 (802.11be) Windows 11 Pro Black
Part number 21KV000EUS
THINKPAD P1 G7 ULTRA 5 135H VPRO16 NT W11P 16GB 1X512GB SSD
- Intel Core Ultra 5 135H, 14C (4P + 8E + 2LPE)/18T, Max Turbo up to 4.6GHz, 18MB
- 16" WUXGA (1920x1200) IPS 400nits 100% sRGB 60Hz TÜV Low Blue Light
- 16GB LPCAMM2 LPDDR5x-7500
- 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
- Intel Arc Graphics
- Windows 11 Pro
- Manufacturer
- Lenovo
- Part number
- 21KV000EUS
- Condition
- New
- Category
- Computer Systems › Portable Computers
- 1GPA category
- Hardware
Overview
The Power You Need in an Advanced AI-Ready System
- 16ʺ mobile workstation for AI-assisted workflows & professional-level graphics
- Enterprise-grade security, manageability & reliability with up to Intel vPro®
- True mobility, sleek design, & advanced Flex Cooling System for long-term reliability
- High-capacity LPCAMM2 memory to run multiple applications simultaneously
- Seamless collaborations through boosted connectivity & network capacity
Specifications
| Product type | Mobile workstation |
|---|---|
| Product colour | Black |
| Form factor | Clamshell |
| Housing material | Aluminium |
| Display diagonal | 40.6 cm (16") |
|---|---|
| Display resolution | 1920 x 1200 pixels |
| Touchscreen | No |
| HD type | WUXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Anti-glare screen | Yes |
| Display brightness | 400 cd/m² |
| RGB colour space | sRGB |
| Colour gamut | 100% |
| Maximum refresh rate | 60 Hz |
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel Core Ultra 5 |
| Processor generation | Intel® Core™ Ultra (Series 1) |
| Processor model | 135H |
| Processor cores | 14 |
| Processor threads | 18 |
| Processor boost frequency | 4.6 GHz |
| Performance cores | 4 |
| Efficient cores | 8 |
| Low Power Efficient-cores | 2 |
| Performance-core Max Turbo Frequency | 4.6 GHz |
| Efficient-core Max Turbo Frequency | 3.6 GHz |
| Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
| Performance-core base frequency | 1.7 GHz |
| Efficient-core base frequency | 1.2 GHz |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Processor cache | 18 MB |
| Processor cache type | Smart Cache |
| Processor base power | 28 W |
| Maximum turbo power | 115 W |
| Neural processor unit (NPU) | Intel AI Boost |
|---|---|
| Maximum frequency NPU | 1.4 GHz |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI datatype support on NPU | FP16, FP32, Int8 |
| AI software frameworks supported by NPU | DirectML, ONNX RT, OpenVINO, Windows ML |
| Internal memory | 16 GB |
|---|---|
| Internal memory type | LPDDR5x-SDRAM |
| Memory clock speed | 7500 MHz |
| Maximum internal memory | 64 GB |
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Optical drive type | No |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Discrete graphics card model | Not available |
|---|---|
| On-board graphics card | Yes |
| On-board GPU manufacturer | Intel |
| Discrete graphics card | No |
| On-board graphics card family | Intel Arc Graphics |
| On-board graphics card model | Intel Arc Graphics |
| Audio chip | Realtek ALC3306 |
|---|---|
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of microphones | 2 |
| Front camera resolution (numeric) | 5 MP |
|---|---|
| Infrared (IR) camera | Yes |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
|---|---|
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Mobile network connection | No |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Near Field Communication (NFC) | No |
| WWAN | Not installed |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Sleep-and-Charge | Yes |
| Motherboard chipset | Intel SoC |
|---|
| Pointing device | ThinkPad UltraNav |
|---|---|
| Numeric keypad | No |
| Keyboard backlit | Yes |
| Operating system architecture | 64-bit |
|---|---|
| Operating system language | English |
| Operating system installed | Windows 11 Pro |
| Bundled software | Intel Connectivity Performance Suite |
| Battery capacity | 90 Wh |
|---|
| AC adapter power | 135 W |
|---|---|
| USB Type-C charging port | Yes |
| USB Power Delivery (USB PD) | Yes |
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Fingerprint reader | Yes |
| Windows Hello | Yes |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Certification | ENERGY STAR,TCO,EPEAT Gold,RoHS |
|---|
| Width | 354.4 mm |
|---|---|
| Depth | 241.2 mm |
| Height | 17.1 mm |
| Weight | 1.82 kg |
| AC adapter included | Yes |
|---|
