Lenovo ThinkPad P14s Gen 5 (Intel) Intel Core Ultra 5 135H Laptop 36.8 cm (14.5") Touchscreen WQXGA 16 GB DDR5-SDRAM 512 GB SSD NVIDIA RTX 500 Ada Wi-Fi 6E (802.11ax) Windows 11 Pro Black English

Part number 21G2001LUS

THINKPAD P14S G5 ULTRA 5 64 16.0GB 1X512GB SSD

Up to Intel® Core™ Ultra 9 185H
Up to Windows® 11 Pro
Up to NVIDIA® RTX 500 Ada Generation 4GB GDDR6
Brand new 14.5" display, up to 3K 430nits, 100% DCI-P3
Standard support for TÜV Low Blue Light, Eyesafe® Certified 2.0

Manufacturer: Lenovo
Part number: 21G2001LUS
Condition: New
Category: Computer Systems › Workstations
1GPA category: Hardware

Overview

ThinkPad P14s Gen 5 Intel

This notebook combines advanced technology with unparalleled durability, setting the standard for high-performance computing. Equipped with up to Intel® H Series Core™ Ultra 9 Processor and optional NVIDIA® RTX 500 GPU, it allows creative professionals to bring their visions to life with unparalleled speed and precision. Whether rendering complex 3D models, editing highresolution videos, or designing immersive digital experiences, it delivers uncompromising performance to enhance the creative output. With support for up to 96GB DDR5 memory, users can tackle multiple tasks simultaneously without any

slowdown.

Specifications

Design
Colour name	Black
Product type	Laptop
Product colour	Black
Form factor	Clamshell
Housing material	Aluminium

Display
Display diagonal	36.8 cm (14.5")
Display resolution	2560 x 1600 pixels
Touchscreen	Yes
HD type	WQXGA
Panel type	IPS
Native aspect ratio	16:10
Anti-glare screen	Yes
Display brightness	350 cd/m²
RGB colour space	sRGB
Colour gamut	100%
Low Blue Light technology	Yes
Maximum refresh rate	90 Hz

Processor
Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor generation	Intel® Core™ Ultra (Series 1)
Processor model	135H
Processor cores	14
Processor threads	18
Processor boost frequency	4.6 GHz
Performance cores	4
Efficient cores	8
Low Power Efficient-cores	2
Performance-core Max Turbo Frequency	4.6 GHz
Efficient-core Max Turbo Frequency	3.6 GHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Performance-core base frequency	1.7 GHz
Efficient-core base frequency	1.2 GHz
Low Power Efficient-core Base Frequency	700 MHz
Processor cache	18 MB
Processor cache type	Smart Cache
Processor base power	28 W
Maximum turbo power	115 W

Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, ONNX RT, OpenVINO, Windows ML

Memory
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory form factor	SO-DIMM
Memory layout (slots x size)	1 x 16 GB
Memory slots	2x SO-DIMM
Maximum internal memory	96 GB
Memory channels	Dual-channel
ECC	No
Non-ECC	Yes

Storage
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
NVMe	Yes
SSD form factor	M.2
M.2 SSD size	2280 (22 x 80 mm)
Optical drive type	No
Card reader integrated	No

Graphics
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA RTX 500 Ada
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR6
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Discrete graphics card	Yes
On-board graphics card family	Intel Arc Graphics
On-board graphics card model	Intel Arc Graphics

Audio
Audio chip	Realtek ALC3287
Audio system	High Definition Audio
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Yes
Number of microphones	2

Camera
Front camera	Yes
Front camera resolution (numeric)	5 MP
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Mobile network connection	No
Antenna type	2x2
WLAN controller model	Intel Wi-Fi 6E AX211
WLAN controller manufacturer	Intel
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3
Near Field Communication (NFC)	No
WWAN	Not installed

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB4 Gen 2x2 ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes
USB Sleep-and-Charge	Yes

Performance
Motherboard chipset	Intel SoC

Keyboard
Pointing device	ThinkPad UltraNav
Numeric keypad	No
Keyboard backlit	Yes
Spill-resistant keyboard	Yes
Keyboard language	English

Software
Operating system architecture	64-bit
Operating system language	English
Operating system installed	Windows 11 Pro

Battery
Battery technology	Lithium Polymer (LiPo)
Battery capacity	75 Wh

Power
AC adapter power	135 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes

Security
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Smart card reader	Yes
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Password protection	Yes
Password protection type	BIOS, SSD, Supervisor, User

Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%

Certificates
Compliance certificates	RoHS

Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, TCO
