Lenovo 21FA0057US
View 1 View 2 View 3 View 4 View 5 View 6 View 7 View 8
Lenovo

Lenovo ThinkPad P16 Gen 2 Intel® Core™ i7 i7-14700HX Mobile workstation 40.6 cm (16") WUXGA 16 GB DDR5-SDRAM 512 GB SSD NVIDIA RTX 1000 Ada Wi-Fi 6E (802.11ax) Windows 11 Pro Black

Part number 21FA0057US

THINKPAD P16 G2 CORE I7-14700HX 3.9G 16GB 512GB SSD 16 NT W11P

  • Intel Core i7-14700HX, 20C (8P + 12E)/28T, P-core 2.1/5.5GHz, E-core 1.5/3.9GHz, 33MB Intel Smart Cache
  • 16" WUXGA (1920x1200) IPS 400nits 100% sRGB TÜV Low Blue Light
  • 2x 8GB SODIMM DDR5-5600 Non-ECC
  • 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
  • NVIDIA RTX 1000 Ada Generation 6GB
  • Windows 11 Pro
Manufacturer
Lenovo
Part number
21FA0057US
Condition
New
Category
Computer Systems › Portable Computers
1GPA category
Hardware

Specifications

Design
Colour nameStorm Grey (Top), Villi Black (Bottom)
Product typeMobile workstation
Product colourBlack
Form factorClamshell
Display back cover materialAluminium
Display
Display diagonal40.6 cm (16")
Display resolution1920 x 1200 pixels
TouchscreenNo
HD typeWUXGA
Panel typeIPS
LED backlightYes
Native aspect ratio16:10
Anti-glare screenYes
Display brightness400 cd/m²
RGB colour spacesRGB
Colour gamut100%
Processor
Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor modeli7-14700HX
Processor cores20
Processor threads28
Processor boost frequency5.5 GHz
Processor frequency2.1 GHz
Memory
Internal memory16 GB
Internal memory typeDDR5-SDRAM
Memory clock speed5600 MHz
Memory form factorSO-DIMM
Memory layout (slots x size)2 x 8 GB
Memory slots4x SO-DIMM
Maximum internal memory192 GB
Storage
Total storage capacity512 GB
Storage mediaSSD
Total SSDs capacity512 GB
Number of SSDs installed1
SSD capacity512 GB
SSD interfacePCI Express 4.0
NVMeYes
SSD form factorM.2
Optical drive typeNo
Card reader integratedYes
Compatible memory cardsSD
Graphics
Discrete graphics card modelNVIDIA RTX 1000 Ada
Discrete graphics card memory6 GB
Discrete graphics memory typeGDDR6
Discrete graphics cardYes
Audio
Audio chipRealtek ALC3306
Number of built-in speakers2
Speaker power2 W
Built-in microphoneYes
Number of microphones2
Camera
Front cameraYes
Front camera resolution1920 x 1080 pixels
Front camera HD typeFull HD
Privacy cameraYes
Privacy typePrivacy shutter
Network
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Wi-Fi standardsWi-Fi 6E (802.11ax)
Mobile network connectionNo
Antenna type2x2
WLAN controller modelIntel Wi-Fi 6E AX211
WLAN controller manufacturerIntel
Ethernet LANNo
BluetoothYes
Bluetooth version5.3
Near Field Communication (NFC)No
WWANNot installed
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
HDMI ports quantity1
HDMI version2.1
Thunderbolt 4 ports quantity2
Intel® Thunderbolt 4Yes
Combo headphone/mic portYes
USB Type-C DisplayPort Alternate ModeYes
USB Sleep-and-ChargeYes
Performance
Motherboard chipsetIntel WM790
Keyboard
Pointing deviceThinkPad UltraNav
Numeric keypadYes
Keyboard backlitYes
Software
Operating system languageEnglish
Operating system installedWindows 11 Pro
Battery
Battery capacity94 Wh
Power
AC adapter power170 W
USB Type-C charging portYes
USB Power Delivery (USB PD)Yes
Security
Cable lock slotYes
Cable lock slot typeKensington
Fingerprint readerYes
Smart card readerNo
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Certificates
CertificationENERGY STAR,TCO,EPEAT Gold,RoHS
Weight & dimensions
Width364 mm
Depth266 mm
Height30.2 mm
Weight2.95 kg
Packaging content
AC adapter includedYes

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
