Products › Computer Systems

Lenovo

Lenovo ThinkPad X1 Yoga (4th Gen) Intel® Core™ i7 i7-10510U Hybrid (2-in-1) 35.6 cm (14") Touchscreen 4K Ultra HD 16 GB LPDDR3-SDRAM 1 TB SSD Wi-Fi 5 (802.11ac) Windows 10 Pro Grey

Part number 20SA000EUS

TOPSELLER TP X1 YOGA 4G CORE I7-10510U 1.8G 16GB 1TB 14IN W10P

  • Windows 10 Pro 64-bit
  • Intel Core i7-10510U (8MB Cache, 1.8GHz)
  • 35.6 cm (14") 4K Ultra HD 3840 x 2160 IPS Touch
  • 16GB (2133MHz) LPDDR3-SDRAM & 1000GB SSD
Manufacturer
Lenovo
Part number
20SA000EUS
Condition
New
Category
Computer Systems › Portable Computers
1GPA category
Hardware

Overview

The ultimate in flexibility

Thinner. Lighter. More secure. The ThinkPad X1 Yoga Gen 4 features the renowned 360-degree hinge to accommodate your style. This 14" 2-in-1 laptop features a built-in suite of ThinkShield security features to protect all your critical data. And with the choice of a 4K display with Dolby Vision™ and Dolby Atmos™ Speaker System, you can take your creativity—and your entertainment—to new levels.

Leave your power cord behind

At 17% smaller than its predecessor, the X1 Yoga Gen 4 features a lightweight aluminum chassis. This 2-in-1 weighs only 1.35kg. With a battery life of up to 18 hours, it begs to accompany you everywhere.* And when you do need more juice, Rapid Charge boosts your battery up to 80% in just 60 minutes—giving you 14.4 more hours unplugged.

* Based on testing with MobileMark 2014. Battery life varies significantly with settings, usage, and other factors.

Raw power, super-speed

Powered by 8th Gen Intel® Core™ processors and robust memory, the X1 Yoga Gen 4 packs a big punch. The PCIe solid-state drive (SSD) delivers speedy performance sure to delight with its responsiveness.

Unlimited creativity

The X1 Yoga Gen 4 includes a rechargeable ThinkPad Pen Pro. Sketch. Sign documents. Take notes. Even color! Never worry about running out of ink or needing batteries, as it charges while it's stored in your system. Plus, with a garaged slot, you won't need to worry about misplacing or leaving it behind. Go ahead and create—there are no limits to where your imagination can take you.

Like a cinema in your lap

With the optional 4K High Dynamic Range (HDR) display, you'll enjoy life-like accuracy. Add Dolby Vision™ into the mix, and you’ll get vibrant visuals where colors pop, contrast is expanded, brightness increases, and details are much more refined. So whether you’re watching a video, Skyping across the world, or sketching, the X1 Yoga Gen 4 delivers a stunning experience. Or choose from several displays, including an FHD panel with PrivacyGuard if you're more concerned with screen security.

Surround sound

The X1 Yoga Gen 4 laptop includes surround-sound with the Dolby Atmos® Speaker System. Two up-firing speakers alongside the keyboard combine with two down-firing woofers on the bottom of the machine. The result? Enhanced audio that seemingly flows all around you. What’s more, four 360-degree microphones cancel unwanted noise when you’re on calls, and pick up your voice from across the room—so you can use voice activation to wake your system, play music, and more.

Built for life's extremes

Like all ThinkPad laptops, the X1 Yoga Gen 4 is tested against 12 military-grade requirements and more than 200 quality checks to ensure it runs in extreme conditions. From the Arctic wilderness to desert dust storms, from zero gravity to spills and drops, you can trust this laptop to handle whatever life throws your way.

Well-connected

When you’re out and about, the X1 Yoga Gen 4 2-in-1 laptop can keep you online even when there’s no WiFi. Choose the optional LTE-A card and the WWAN technology lets your laptop function like a smartphone—where there’s cellular service you can always jump online. And you can trust that your connection is secure.

*WWAN must be configured at time of purchase, as it’s not upgradeable.

We’ve got your back—and your front

Keep your business data—and your privacy—safe with the X1 Yoga Gen 4 laptop’s comprehensive suite of ThinkShield security features. Its discrete Trusted Platform Module (dTPM) encrypts data and works in conjunction with Windows 10 Pro security. ThinkShutter, a physical camera cover, blocks the lens to ensure that you’re only seen when you want to be. And the fingerprint reader uses biometrics to log you in with a simple touch.

For your eyes only

As part of ThinkShield security, we offer a combination of hardware and software that work together to ensure what’s on your display is for your eyes only. PrivacyGuard is an electronic privacy filter built into your system that decreases the angle of vision on your display, such that only your eyes, when facing head-on, can see content. All others see a darkened screen. PrivacyAlert* is an integrated software that works with the IR camera to ensure that if others look over your shoulder, then a popup notifies you of the potential threat.

*Requires the optional IR camera.

Specifications

Design
Colour nameIron Grey
Product typeHybrid (2-in-1)
Product colourGrey
Form factorConvertible (Folder)
Housing materialAluminium, Magnesium
Display
Touchscreen typeCapacitive
Display diagonal35.6 cm (14")
Display resolution3840 x 2160 pixels
TouchscreenYes
HD type4K Ultra HD
Touch technologyMulti-touch
Panel typeIPS
LED backlightYes
Native aspect ratio16:9
Display brightness470 cd/m²
Dual-screenNo
Contrast ratio (typical)1400:1
Processor
Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation10th gen Intel® Core™ i7
Processor modeli7-10510U
Processor cores4
Processor threads8
Processor boost frequency4.9 GHz
Processor frequency1.8 GHz
System bus rate4 GT/s
Processor cache8 MB
Processor socketBGA 1528
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameComet Lake
Thermal Design Power (TDP)15 W
Configurable TDP-up frequency2.3 GHz
Configurable TDP-up25 W
Configurable TDP-down10 W
Configurable TDP-down frequency0.8 GHz
Tjunction100 °C
Maximum number of PCI Express lanes16
PCI Express slots version3.0
PCI Express configurations1x4, 2x2, 1x2+2x1, 4x1
Memory
Internal memory16 GB
Internal memory typeLPDDR3-SDRAM
Memory clock speed2133 MHz
Memory form factorOn-board
Maximum internal memory16 GB
Maximum internal memory (64-bit)16 GB
Storage
Total storage capacity1 TB
Storage mediaSSD
Total SSDs capacity1 TB
Number of SSDs installed1
SSD capacity1 TB
SSD interfaceNVMe, PCI Express
NVMeYes
SSD form factorM.2
Optical drive typeNo
Card reader integratedNo
Graphics
Discrete graphics card modelNot available
On-board graphics cardYes
On-board GPU manufacturerIntel
Discrete graphics cardNo
On-board graphics card familyIntel® UHD Graphics
On-board graphics card modelIntel® UHD Graphics
On-board graphics card base frequency300 MHz
On-board graphics card dynamic frequency (max)1150 MHz
Maximum on-board graphics card memory32 GB
Number of execution units24
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
On-board graphics card ID0x9B41
Audio
Audio chipRealtek ALC3286
Number of built-in speakers4
Built-in microphoneYes
Camera
Front cameraYes
Front camera signal format720p
Front camera HD typeHD
Infrared (IR) cameraYes
Privacy cameraYes
Privacy typePrivacy shutter
Auto focusNo
Network
Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Antenna type2x2
WLAN controller modelIntel Dual Band Wireless-AC 9560
BluetoothYes
Bluetooth version5.0
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity2
HDMI ports quantity1
HDMI version1.4b
Combo headphone/mic portYes
Docking connectorYes
USB Type-C DisplayPort Alternate ModeYes
USB Sleep-and-ChargeYes
USB Sleep-and-Charge ports1
Keyboard
Pointing deviceThinkPad UltraNav
Numeric keypadNo
Keyboard backlitYes
Spill-resistant keyboardYes
Windows keysYes
Software
Operating system architecture64-bit
Operating system installedWindows 10 Pro
Processor special features
Intel® My WiFi Technology (Intel® MWT)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Enhanced Intel SpeedStep TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel Clear Video TechnologyYes
Intel® Quick Sync Video TechnologyYes
Intel Flex Memory AccessYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® Secure KeyYes
Intel TSX-NINo
Intel Stable Image Platform Program (SIPP)No
Intel® OS GuardYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel 64Yes
Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes
Processor package size46 x 24 mm
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
CPU configuration (max)1
Embedded options availableNo
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Processor ARK ID196449
Battery
Battery technologyLithium-Ion (Li-Ion)
Battery capacity51 Wh
Battery life (max)18.1 h
Fast chargingYes
Power
AC adapter power65 W
USB Type-C charging portYes
USB Power Delivery (USB PD)Yes
Security
Cable lock slotYes
Fingerprint readerYes
Smart card readerNo
Trusted Platform Module (TPM)Yes
Password protectionYes
Password protection typeHDD, Power on, Supervisor
Certificates
Compliance certificatesRoHS
Sustainability
Sustainability certificatesEPEAT Gold, ENERGY STAR
Weight & dimensions
Width323 mm
Depth218 mm
Height15.5 mm
Weight1.36 kg
Packaging content
AC adapter includedYes
ManualYes
Warranty cardYes

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
