Lenovo ThinkCentre M70q Gen 5 Intel® Core™ i5 i5-14400T 16 GB DDR5-SDRAM 256 GB SSD Windows 11 Pro Mini PC Black
Part number 12TD001UUS
THINKCENTRE M70Q G5 I5-14400T E-CORES 3.2G 16GB 256GB SSD W11P
- Intel Core i5-14400T, 10C (6P + 4E)/16T, P-core 1.5/4.5GHz, E-core 1.1/3.2GHz, 20MB
- 1x 16GB SO-DIMM DDR5-4800
- 256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal
- Intel UHD Graphics 730
- Windows 11 Pro
- Manufacturer
- Lenovo
- Part number
- 12TD001UUS
- Condition
- New
- Category
- Computer Systems › Desktop Computers
- 1GPA category
- Hardware
Overview
ThinkCentre M70q Gen 5
Equipped with up to 14th Gen Intel® Core™ i7 processors and 64GB DDR5 memory, this desktop offers lightning-fast speeds for demanding industry tasks. Up to 4TB SSD storage ensures ample room for large files and datasets. Ideal for data analysis, software development, or system implementation, its advanced hardware enables professionals to work efficiently on the go. The robust performance and vast storage allow users to concentrate on innovation without delays from their tools.
Intel® UHD graphics and its support for up to four independent displays enhances multitasking capabilities for professionals engaged in data analysis, drafting, content development, and project management, thereby boosting productivity through seamless, versatile workflows.
Stay connected anywhere with Wi-Fi 6E, ensuring fast, reliable wireless connectivity. Versatile ports including DisplayPort, USB-C, USB-A, and HDMI enhance productivity for stationary professionals using this desktop.
Its compact 1L form factor maximizes space efficiency, fitting seamlessly into any workspace while delivering robust performance, making it an ideal choice for those seeking functionality without sacrificing valuable desk space.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | Intel® Core™ i5 (14th gen) |
| Processor model | i5-14400T |
| Processor cores | 10 |
| Processor threads | 16 |
| Processor boost frequency | 4.5 GHz |
| Performance cores | 6 |
| Efficient cores | 4 |
| Performance-core Max Turbo Frequency | 4.5 GHz |
| Efficient-core Max Turbo Frequency | 3.2 GHz |
| Performance-core base frequency | 1.5 GHz |
| Efficient-core base frequency | 1.1 GHz |
| Processor cache | 20 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Processor base power | 35 W |
| Maximum turbo power | 82 W |
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 2x DIMM |
| Memory clock speed | 4800 MHz |
| ECC | No |
| Non-ECC | Yes |
| Memory channels | Dual-channel |
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Card reader integrated | No |
| Discrete graphics card | No |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 730 |
| Motherboard chipset | Intel Q670 |
|---|---|
| Password protection | Yes |
| Password protection type | BIOS, HDD, Power on, Supervisor |
| Trusted Platform Module (TPM) | Yes |
| Product type | Mini PC |
| Trusted Platform Module (TPM) version | 2.0 |
| Built-in speaker(s) | Yes |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4a |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| M.2 card slot (wireless) | 1 |
| M.2 card slot (storage) | 2 |
| Number of rear USB ports | 4 |
| Number of front USB ports | 3 |
| Number of front audio ports | 1 |
| Power supply | 90 W |
|---|---|
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50/60 Hz |
| Chassis type | Mini PC |
|---|---|
| Colour name | Black |
| Volume | 1 L |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Operating system architecture | 64-bit |
|---|---|
| Operating system language | English |
| Operating system installed | Windows 11 Pro |
| Display included | No |
|---|
| Audio chip | Realtek ALC233VB |
|---|---|
| Audio system | High Definition Audio |
| Number of speakers | 1 |
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Width | 179 mm |
|---|---|
| Depth | 182.9 mm |
| Height | 36.5 mm |
| Weight | 1.25 kg |
| Package width | 490 mm |
|---|---|
| Package depth | 128 mm |
| Package height | 250 mm |
| Package weight | 3.2 kg |
| Mouse included | Yes |
|---|---|
| Mouse connectivity | Wired |
| Keyboard included | Yes |
| Compliance certificates | RoHS |
|---|---|
| Certification | ENERGY STAR,TCO,EPEAT Silver,RoHS |
| Sustainability certificates | ENERGY STAR, EPEAT Silver, ErP, GREENGUARD, TCO |
|---|
| Keyboard connectivity | Wired |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
