Lenovo ThinkCentre M90a Intel® Core™ i5 i5-12500 60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 16 GB DDR4-SDRAM 512 GB SSD NVIDIA GeForce MX550 Windows 11 Pro Wi-Fi 6 (802.11ax) Black
Part number 11VF0068US
TOPSELLER TC M90A I5-12500 3.0G 16GB 512GB 23.8IN W11P
- Windows 11 Pro 64-bit
- Intel Core i5-12500 (18MB Cache)
- 60.5 cm (23.8") Full HD 1920 x 1080 IPS, NVIDIA GeForce MX550 (2GB GDDR6)
- 16GB (3200MHz) DDR4-SDRAM (1 x 16) & 512GB SSD
- Manufacturer
- Lenovo
- Part number
- 11VF0068US
- Condition
- New
- Category
- Computer Systems › Desktop Computers
- 1GPA category
- Hardware
Overview
Engineered for the modern workplace
Meet the ThinkCentre M90a Gen 3 all-in-one, a premium desktop PC for today’s work-from-anywhere world. Sleek, secure, and smart, it’s powered by up to 12th Gen Intel® Core™ i9 with Intel vPro® platform and optional NVIDIA® graphics. While its AI noise-suppression and Dolby Atmos® audio enhance your videoconferences, the phone and keyboard docks help save on desk space.
Protecting your data, ideas, & more
With ThinkCentre comes ThinkShield, end-to-end security combining industry-leading hardware, software, and services. The ThinkCentre M90a Gen 3 all-in-one also taps up to Intel vPro® Enterprise for hardware-enhanced PC protection. Other safeguards include BIOS-based Smart USB Protection and an physical shutter to close the webcam.
Meetings will never be the same again
With an industry-first tiltable camera and an optional conference call base, every meeting runs more seamlessly. Quad-array far-field microphones, with 360-degree pickup, use AI to suppress annoying background sound. As well as four Harman® speakers, super-fast USB-C connectivity brings even more clarity and richness to your meetings, while a single click fires up Microsoft Teams.
Cooler, quieter, smarter
Thanks to our Intelligent Cooling Engine (ICE) 4.0, the ThinkCentre M90a Gen 3 all-in-one has different power modes based on your computing needs. Boost the power by up to 15%, lower normal system noise by three decibels, or go for maximum cooling. This very modern PC also has optional smart human presence detection that knows when you’re away, enabling a new level of security and energy efficiency.
Pushed to the limit, & then some
As well as our own rigorous in-house tests, the ThinkCentre M90a Gen 3 all-in-one is measured against 12 US military-grade requirements, including more than 200 quality checks to ensure it can run in extreme conditions. They cover harsh variables like Arctic wilderness and desert dust storms, including tests for temperature, pressure, humidity, vibration, and more.
Sustainably designed & packaged
By 2025, Lenovo is committed to obtaining 90% of our global operations electricity from renewable sources, removing one-million tons of greenhouse gas emissions from our supply chain. It’s why this all-in-one PC, for instance, comes with 90% sustainable packaging and comprises recycled materials. And why it also meets global standards for energy-efficiency and health & safety.
Specifications may vary depending upon region.
Specifications
| Display diagonal | 60.5 cm (23.8") |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display brightness | 250 cd/m² |
| Panel type | IPS |
| RGB colour space | NTSC |
| Anti-glare screen | Yes |
| Colour gamut | 72% |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 70° |
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor model | i5-12500 |
| Processor cores | 6 |
| Processor boost frequency | 4.6 GHz |
| Performance cores | 6 |
| Performance-core Max Turbo Frequency | 4.6 GHz |
| Performance-core base frequency | 3 GHz |
| Processor cache | 18 MB |
| Processor cache type | Smart Cache |
| Bus type | DMI4 |
| Processor base power | 65 W |
| Maximum turbo power | 117 W |
| Internal memory | 16 GB |
|---|---|
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 64 GB |
| Memory slots | 2 |
| Memory slots type | SO-DIMM |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory form factor | DIMM/SO-DIMM |
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Optical drive type | No |
| Card reader integrated | No |
| Discrete graphics card | Yes |
|---|---|
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA GeForce MX550 |
| Discrete graphics card memory | 2 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card | Yes |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
| Built-in speaker(s) | Yes |
|---|---|
| Number of speakers | 2 |
| RMS rated power | 6 W |
| Built-in microphone | Yes |
| Audio system | HD |
| Built-in camera | Yes |
|---|---|
| Total megapixels | 5 MP |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
| Wi-Fi | Yes |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| Antenna type | 2x2 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| Ethernet LAN (RJ-45) ports | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| Product colour | Black |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Product type | All-in-One PC |
|---|---|
| Motherboard chipset | Intel Q670 |
| Trusted Platform Module (TPM) | Yes |
| BIOS password | Yes |
| HDD user password | Yes |
| Operating system architecture | 64-bit |
|---|---|
| Operating system language | English |
| Operating system installed | Windows 11 Pro |
| CPU configuration (max) | 1 |
|---|
| AC adapter power | 230 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Width (with stand) | 539.6 mm |
|---|---|
| Depth (with stand) | 216.3 mm |
| Height (with stand) | 472 mm |
| Weight (with stand) | 8.74 kg |
| Width (without stand) | 539.6 mm |
| Depth (without stand) | 216.3 mm |
| Height (without stand) | 387.6 mm |
| Package width | 660 mm |
| Package depth | 238 mm |
| Package height | 545 mm |
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Compliance certificates | RoHS |
|---|---|
| Certification | TÜV MIL-STD-810H UL Anti-dust |
| Sustainability certificates | TCO, ErP |
|---|
| Mouse included | Yes |
|---|---|
| Keyboard included | Yes |
| Keyboard language | English |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
