Lenovo
Lenovo ThinkCentre M90s Gen 3 Intel® Core™ i7 i7-12700 16 GB DDR5-SDRAM 256 GB SSD Windows 11 Pro SFF PC Black
Part number 11TT003PUS
THINKCENTRE M90S I7-12700 VPRO 3.6G 16GB 256GB SSD W11P
- Intel Core i7-12700, 12C (8P + 4E)/20T, Max Turbo up to 4.9GHz, P-core 2.1/4.8GHz, E-core 1.6/3.6GHz, 25MB
- 1x 16GB UDIMM DDR5-4400
- 256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal
- Intel UHD Graphics 770
- Windows 11 Pro
- Manufacturer
- Lenovo
- Part number
- 11TT003PUS
- Condition
- New
- Category
- Computer Systems › Desktop Computers
- 1GPA category
- Hardware
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i7 |
| Processor model | i7-12700 |
| Processor cores | 12 |
| Processor threads | 20 |
| Processor boost frequency | 4.8 GHz |
| Processor frequency | 2.1 GHz |
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 128 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 4400 MHz |
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | DVD±RW |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | No |
| Discrete graphics card | No |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
| Motherboard chipset | Intel Q670 |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Product type | PC |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Wi-Fi | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| DisplayPorts quantity | 3 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Microphone in | Yes |
| Power supply | 310 W |
|---|
| Chassis type | SFF |
|---|---|
| Volume | 8.2 L |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Operating system language | English |
|---|---|
| Operating system installed | Windows 11 Pro |
| Audio chip | Realtek ALC897Q-CG |
|---|---|
| Audio system | High Definition Audio |
| Number of speakers | 1 |
| Width | 92.5 mm |
|---|---|
| Depth | 297.7 mm |
| Height | 339.5 mm |
| Weight | 5.3 kg |
| Mouse included | Yes |
|---|---|
| Mouse connectivity | Wired |
| Keyboard included | Yes |
| Certification | ENERGY STAR,TCO,EPEAT Silver,RoHS |
|---|
| Keyboard connectivity | Wired |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
