Lenovo ThinkCentre M90s Intel® Core™ i9 i9-12900 16 GB DDR5-SDRAM 1 TB SSD Windows 11 Pro SFF PC Black
Part number 11TT001CUS
DESKTOP TC M90S GEN 3 I912900 1 16G N W11P
- Windows 11 Pro
- Intel Core i9-12900 (30MB Cache)
- 16GB (4400MHz) DDR5-SDRAM & 1000GB SSD
- Manufacturer
- Lenovo
- Part number
- 11TT001CUS
- Condition
- New
- Category
- Computer Systems › Desktop Computers
- 1GPA category
- Hardware
Overview
Standout performance
No program is too complex or file too large for the ThinkCentre M90s Gen 3 (Intel). This small form factor desktop PC is packed with up to Intel vPro® Enterprise with 12th Gen Intel® Core™ i9 processors for real-world, business-class performance. Plus, with up to Intel® Iris® Xe graphics, you can power through hi-res renderings, video editing, and VR/AR content with ease.
Built-in protection
The ThinkCentre M90s Gen 3 has Lenovo ThinkShield, end-to-end hardware and software solutions to protect your data—and your business. In addition to your passwords being encrypted, BIOS-based Smart USB protection prevents unauthorized system access. This desktop PC can even self-heal if it becomes corrupted and has several physical security options to thwart theft.
Flexible & expandable
With the ThinkCentre M90s Gen 3, you can connect to legacy peripherals and have the option to tap into the latest WiFi 6E* connectivity. You can also opt for solid-state drive (SSD) storage for improved responsiveness and power consumption, as well as faster boot ups and application launches. Plus, there are ample I/O ports and expansion slots to meet your ever-changing IT needs.
*WiFi 6E requires Windows 11 Pro. Operation is dependent on the support of the operating system, routers/APs/gateways that support WiFi 6E, along with the regional regulatory certifications and spectrum allocation.
Durable & reliable
As well as our own rigorous in-house tests, the ThinkCentre M90s Gen 3 is measured against the US Department of Defense's MIL-STD 810H standards, including more than 200 quality checks to ensure it can run in extreme conditions. They cover harsh variables like Arctic wilderness and desert dust storms, including tests for temperature, pressure, humidity, vibration, and more.
Specifications may vary depending upon region.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i9 |
| Processor generation | 12th gen Intel® Core™ i9 |
| Processor model | i9-12900 |
| Processor cores | 16 |
| Processor boost frequency | 5.1 GHz |
| Processor cache | 30 MB |
| Processor cache type | Smart Cache |
| Bus type | DMI4 |
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 128 GB |
| Internal memory type | DDR5-SDRAM |
| Memory slots | 4x DIMM |
| Memory clock speed | 4400 MHz |
| Memory channels | Dual-channel |
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | DVD±RW |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | No |
| Discrete graphics card | No |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card model | Intel UHD Graphics 770 |
| Motherboard chipset | Intel Q670 |
|---|---|
| Password protection | Yes |
| Password protection type | Power on, Supervisor, HDD |
| Trusted Platform Module (TPM) | Yes |
| Product type | PC |
| Built-in speaker(s) | Yes |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 1000,100 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| LAN controller | Intel® I219-LM |
| Wi-Fi | No |
| Bluetooth | No |
| Wake-on-LAN ready | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| DisplayPorts quantity | 3 |
| DisplayPort version | 1.4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Microphone in | Yes |
| Power supply | 380 W |
|---|---|
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
| Chassis type | SFF |
|---|---|
| Volume | 8.2 L |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Viewing window | No |
| Operating system language | English |
|---|---|
| Operating system installed | Windows 11 Pro |
| Intel 64 | Yes |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Idle States | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Display included | No |
|---|
| Audio chip | Realtek ALC897Q-CG |
|---|---|
| Audio system | High Definition Audio |
| Number of speakers | 1 |
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Width | 92.5 mm |
|---|---|
| Depth | 297.7 mm |
| Height | 339.5 mm |
| Weight | 5.3 kg |
| Package width | 195 mm |
|---|---|
| Package depth | 395 mm |
| Package height | 530 mm |
| Package weight | 7.6 kg |
| Mouse included | Yes |
|---|---|
| Keyboard included | Yes |
| Compliance certificates | RoHS |
|---|---|
| Certification | ErP Lot 3 MIL-STD-810H |
| Sustainability certificates | TCO |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
