Overview
This small form factor is a workhorse full of powerful features and fits seamlessly into evolving workplaces. Powered by the latest 12th Gen Intel Core Processors and up to 128 GB ultra-responsive DDR5 memory, it makes working on multiple applications and compute-intensive tasks faster and smoother. Edit photos or videos, render 3D animations, or simply play games with excellent visuals, thanks to its onboard highperformance graphics like Intel UHD 770 and discrete Intel Iris and AMD Radeon graphics.
Specifications
Processor
| Processor manufacturer | Intel |
|---|
| Processor family | Intel® Core™ i9 |
|---|
| Processor generation | 12th gen Intel® Core™ i9 |
|---|
| Processor model | i9-12900 |
|---|
| Processor cores | 16 |
|---|
| Processor boost frequency | 5.1 GHz |
|---|
| Processor cache | 30 MB |
|---|
| Bus type | DMI4 |
|---|
Memory
| Internal memory | 16 GB |
|---|
| Maximum internal memory | 128 GB |
|---|
| Internal memory type | DDR5-SDRAM |
|---|
| Memory slots | 4x DIMM |
|---|
| Memory clock speed | 4400 MHz |
|---|
| Memory channels | Dual-channel |
|---|
Storage
| Total storage capacity | 256 GB |
|---|
| Storage media | SSD |
|---|
| Optical drive type | DVD±RW |
|---|
| Total SSDs capacity | 256 GB |
|---|
| Number of SSDs installed | 1 |
|---|
| SSD capacity | 256 GB |
|---|
| SSD interface | NVMe, PCI Express 4.0 |
|---|
| NVMe | Yes |
|---|
| SSD form factor | M.2 |
|---|
| Card reader integrated | No |
|---|
Graphics
| Discrete graphics card | No |
|---|
| On-board graphics card | Yes |
|---|
| Discrete graphics card model | Not available |
|---|
| On-board GPU manufacturer | Intel |
|---|
| On-board graphics card model | Intel UHD Graphics 770 |
|---|
Performance
| Motherboard chipset | Intel Q670 |
|---|
| Password protection | Yes |
|---|
| Password protection type | Power on, Supervisor, HDD |
|---|
| Trusted Platform Module (TPM) | Yes |
|---|
| Product type | PC |
|---|
| Built-in speaker(s) | Yes |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Ethernet LAN data rates | 1000,100 Mbit/s |
|---|
| Cabling technology | 10/100/1000Base-T(X) |
|---|
| Wi-Fi | Yes |
|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
|---|
| WLAN controller manufacturer | Intel |
|---|
| WLAN controller model | Intel Wi-Fi 6E AX211 |
|---|
| Antenna type | 2x2 |
|---|
| Bluetooth | Yes |
|---|
| Bluetooth version | 5.2 |
|---|
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
|---|
| DisplayPorts quantity | 2 |
|---|
| DisplayPort version | 1.4 |
|---|
| HDMI ports quantity | 1 |
|---|
| HDMI version | 2.1 |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Combo headphone/mic port | Yes |
|---|
| Line-out | Yes |
|---|
| Microphone in | Yes |
|---|
| PS/2 ports quantity | 2 |
|---|
Power
| Power supply | 260 W |
|---|
| Power supply input voltage | 100 - 240 V |
|---|
Design
| Chassis type | SFF |
|---|
| Volume | 8.2 L |
|---|
| Placement supported | Horizontal/Vertical |
|---|
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
| Product colour | Black |
|---|
| Viewing window | No |
|---|
Software
| Operating system architecture | 64-bit |
|---|
| Operating system language | English |
|---|
| Operating system installed | Windows 11 Pro |
|---|
Processor special features
| Intel 64 | Yes |
|---|
| Enhanced Intel SpeedStep Technology | Yes |
|---|
| Embedded options available | No |
|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
|---|
| Idle States | Yes |
|---|
| Intel Stable Image Platform Program (SIPP) | Yes |
|---|
| Intel Trusted Execution Technology | Yes |
|---|
| Execute Disable Bit | Yes |
|---|
| CPU configuration (max) | 1 |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
|---|
| Intel Virtualization Technology (VT-x) | Yes |
|---|
Display
| Display included | No |
|---|
Audio
| Audio system | High Definition Audio |
|---|
| Number of speakers | 1 |
|---|
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|
| Storage temperature (T-T) | -40 - 60 °C |
|---|
| Operating relative humidity (H-H) | 20 - 80% |
|---|
| Storage relative humidity (H-H) | 10 - 90% |
|---|
| Operating altitude | 0 - 3048 m |
|---|
| Non-operating altitude | 0 - 12192 m |
|---|
Weight & dimensions
| Width | 92.5 mm |
|---|
| Depth | 297.7 mm |
|---|
| Height | 339.5 mm |
|---|
| Weight | 5.3 kg |
|---|
Packaging data
| Package width | 195 mm |
|---|
| Package depth | 395 mm |
|---|
| Package height | 530 mm |
|---|
| Package weight | 7.6 kg |
|---|
Packaging content
| Mouse included | Yes |
|---|
| Keyboard included | Yes |
|---|
Certificates
| Compliance certificates | RoHS |
|---|
| Certification | ErP Lot 3, MIL-STD-810H |
|---|
Sustainability
| Sustainability certificates | TCO |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
