Lenovo ThinkCentre M80s Intel® Core™ i7 i7-10700 16 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro SFF PC Black
Part number 11CU001BUS
TOPSELLER TC M80S I710700 2.9G16GB 512GB SSD DVDRAMBO W10P 64
- PC Black 260 W
- Intel® Core™ i7 i7-10700 2.9 GHz Processor cores: 8
- 16 GB DDR4-SDRAM 2933 MHz 1 x 16 GB
- 512 GB SSD DVD±RW
- Intel® UHD Graphics 630
- Ethernet LAN 10,100,1000 Mbit/s
- Windows 10 Pro 64-bit
- Manufacturer
- Lenovo
- Part number
- 11CU001BUS
- Condition
- New
- Category
- Computer Systems › Desktop Computers
- 1GPA category
- Hardware
Overview
Efficiency & power
The ThinkCentre M80s SFF PC was designed to efficiently tackle all your business tasks. Powerful 10th Gen Intel® Core™ processors and fast DDR4 memory let you multitask with ease, handling anything from email to complex data operations. Further boost productivity with dedicated graphics options.
Fast, reliable storage
Accelerate boot-up, searching, and opening files with optional M.2 solid-state drive (SSD) storage, while 3D NAND technology gives your SSD more reliable performance and improved power consumption.
Comprehensive security for data & device
With Lenovo’s ThinkShield security solutions, hardware and software work together to protect your system and data. The dTPM 2.0 chip encrypts your passwords and data, while BIOS-based Smart USB Protection prevents unauthorized access via peripheral. Physically secure the device itself with multiple features and rely on the advanced data protection of the Intel® vPro™ platform.
Easy to use & manage
The ThinkCentre M80s SFF desktop is compact enough to use on top of your desk, but even if it's underneath, you can turn it on via your keyboard—and its optional ThinkCentre Vertical Stand provides extra stability and gives it an upward-facing angle. The optional Intel® vPro™ platform offers superb remote manageability, plus the PC supports up to three independent monitors and a host of peripherals. Should you need to further configure your PC, its expansion slots make upgrades a snap.
Saves space & looks great
The 8.2 Liter ThinkCentre M80s has a super-compact footprint and is easy to deploy. Its Raven Black chassis has a clean, modern design that fits the evolving workspace. This PC will look great in any office, wherever you put it.
Green design, comfortable usage
The ThinkCentre M80s meets multiple global sustainability standards, including Energy Star® 8.0, EPEAT® Silver, RoHS, and more. It’s also certified for low noise emission by TÜV Rheinland, so this PC is both eco- and employee-friendly.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i7 |
| Processor generation | 10th gen Intel® Core™ i7 |
| Processor model | i7-10700 |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 4.8 GHz |
| Processor frequency | 2.9 GHz |
| Processor cache | 16 MB |
| Processor cache type | Smart Cache |
| System bus rate | 8 GT/s |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Comet Lake |
| Thermal Design Power (TDP) | 65 W |
| Tjunction | 100 °C |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 16 |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Processor socket | LGA 1200 (Socket H5) |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2933 MHz |
| Memory bandwidth supported by processor (max) | 45.8 GB/s |
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 128 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 2933 MHz |
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | DVD±RW |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
| Card reader integrated | No |
| Discrete graphics card | No |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card model | Intel® UHD Graphics 630 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| Maximum on-board graphics card memory | 64 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x9BC5 |
| Motherboard chipset | Intel Q470 |
|---|---|
| Password protection | Yes |
| Password protection type | HDD, Power on, Supervisor |
| Trusted Platform Module (TPM) | Yes |
| Product type | PC |
| Built-in speaker(s) | Yes |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| DisplayPorts quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Line-out | Yes |
| Microphone in | Yes |
| DVI port | No |
| Power supply | 260 W |
|---|
| Chassis type | SFF |
|---|---|
| Colour name | Black |
| Volume | 8.2 L |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Operating system architecture | 64-bit |
|---|---|
| Operating system installed | Windows 10 Pro |
| Intel 64 | Yes |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel Clear Video Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Processor package size | 37.5 x 37.5 mm |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2015C |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 199316 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Display included | No |
|---|
| Audio chip | Realtek ALC623-CG |
|---|---|
| Audio system | High Definition Audio |
| Number of speakers | 1 |
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 20 - 80% |
| Operating altitude | -15.2 - 3048 m |
| Non-operating altitude | -15.2 - 10668 m |
| Width | 93 mm |
|---|---|
| Depth | 298 mm |
| Height | 340 mm |
| Weight | 5.3 kg |
| Mouse included | Yes |
|---|---|
| Keyboard included | Yes |
| Compliance certificates | RoHS |
|---|
| Sustainability certificates | ENERGY STAR |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
