Overview
A desktop that can travel
The HP Elite Mini 800 Desktop PC delivers the high-performance needed to develop complex presentations, crunch big numbers, and quickly create compelling content. Equipped with a powerful Intel processor[2], responsive graphics, and smart deployment options, this is the right PC for big jobs done in small spaces.
Specifications
Processor
| Processor manufacturer | Intel |
|---|
| Processor family | Intel® Core™ i5 |
|---|
| Processor generation | Intel® Core™ i5 (14th gen) |
|---|
| Processor model | i5-14500T |
|---|
| Processor cores | 14 |
|---|
| Processor threads | 20 |
|---|
| Processor boost frequency | 4.8 GHz |
|---|
| Performance cores | 6 |
|---|
| Efficient cores | 8 |
|---|
| Performance-core Max Turbo Frequency | 4.8 GHz |
|---|
| Efficient-core Max Turbo Frequency | 3.4 GHz |
|---|
| Performance-core base frequency | 1.7 GHz |
|---|
| Efficient-core base frequency | 1.2 GHz |
|---|
| Processor cache | 24 MB |
|---|
| Processor cache type | L3 |
|---|
| Processor base power | 35 W |
|---|
| Maximum turbo power | 92 W |
|---|
Memory
| Internal memory | 16 GB |
|---|
| Maximum internal memory | 64 GB |
|---|
| Internal memory type | DDR5-SDRAM |
|---|
| Memory layout (slots x size) | 1 x 16 GB |
|---|
| Memory slots | 2x SO-DIMM |
|---|
| Memory clock speed | 4800 MHz |
|---|
Storage
| Total storage capacity | 512 GB |
|---|
| Storage media | SSD |
|---|
| Optical drive type | No |
|---|
| Total SSDs capacity | 512 GB |
|---|
| Number of SSDs installed | 1 |
|---|
| SSD capacity | 512 GB |
|---|
| SSD memory type | TLC |
|---|
| SSD interface | PCI Express 4.0 |
|---|
| NVMe | Yes |
|---|
Graphics
| Discrete graphics card | No |
|---|
| On-board graphics card | Yes |
|---|
| Discrete graphics card model | Not available |
|---|
| On-board GPU manufacturer | Intel |
|---|
| On-board graphics card family | Intel® UHD Graphics |
|---|
| On-board graphics card model | Intel UHD Graphics 770 |
|---|
Performance
| Market positioning | Business |
|---|
| Password protection | Yes |
|---|
| Password protection type | BIOS, Power on |
|---|
| Trusted Platform Module (TPM) | Yes |
|---|
| Product type | Mini PC |
|---|
| Trusted Platform Module (TPM) version | 2.0 |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Wi-Fi | Yes |
|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
|---|
| WLAN controller manufacturer | Intel |
|---|
| WLAN controller model | Intel Wi-Fi 6E AX211 |
|---|
| Antenna type | 2x2 |
|---|
| Bluetooth | Yes |
|---|
| Bluetooth version | 5.2 |
|---|
Ports & interfaces
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
|---|
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
|---|
| DisplayPorts quantity | 2 |
|---|
| DisplayPort version | 1.4 |
|---|
| HDMI ports quantity | 1 |
|---|
| HDMI version | 2.1 |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
Power
| Power supply | 90 W |
|---|
| Power supply input voltage | 100 - 240 V |
|---|
| Power supply input frequency | 50/60 Hz |
|---|
Design
| Chassis type | Mini PC |
|---|
| Product colour | Black |
|---|
Software
| Operating system installed | Windows 11 Pro |
|---|
Display
| Display included | No |
|---|
Brand-specific features
| HP Support Assistant | Yes |
|---|
| HP Software provided | HP Notifications; HP PC Hardware Diagnostics UEFI; HP Connection Optimizer; HP Privacy Settings; HP PC Hardware Diagnostics Windows; HP Desktop Support Utilities; MyHP; HP Easy Clean; Touchpoint Customizer for Commercial; HP Easy Clean Keyboard Driver; HSA Fusion for Commercial; HSA Telemetry for Commercial |
|---|
| HP segment | Business |
|---|
Audio
| Audio chip | Realtek ALC3252 |
|---|
Weight & dimensions
| Width | 177 mm |
|---|
| Depth | 175 mm |
|---|
| Height | 34 mm |
|---|
| Weight | 1.42 kg |
|---|
Packaging content
| Mouse included | Yes |
|---|
| Mouse connectivity | Wired |
|---|
| Keyboard included | Yes |
|---|
Keyboard
| Keyboard connectivity | Wired |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
