JBL CSA 180Z 1.0 channels Home Black
Part number NCSA180Z-U-US
NCSA180Z-U-US 1 X 80W DRIVECORE AMPLIFIER FANLESS
- 1.0 channels
- Signal-to-Noise Ratio (SNR): 100 dB
- Speakers connectivity type: RCA
- 3.1 kg
- Black
- Manufacturer
- Harman
- Part number
- NCSA180Z-U-US
- Condition
- New
- Category
- Accessories › A/V Accessories
Overview
By combining years of innovation, invention and insight from HARMAN brands, JBL® Commercial Series Amplifiers (CSA) go well beyond the expected in generating powerful sound.
From the switch-mode universal power supply to the efficient performance of Crown’s DriveCore™ Technology, we continue to set new standards in commercial power amplifier technology.
Simple to configure, the CS amp provides a DriveCore-based sound solution. This replaces up to 500 parts with one small chip, significantly reducing the part count and increasing reliability while maintaining superb performance.
Supporting 70V and 100V installations out of the box, CS amps include RJ45 connectors for use with JBL CSR-V in-wall volume controls. Its universal power supply allows every CS amp to accept AC voltages from 100 to 240 VAC, 50/60 Hz.
And with HARMAN’s GreenEdge™ environmental initiative, CS amps quickly pay for themselves in energy savings.
Specifications
| Audio output channels | 1.0 channels |
|---|---|
| Signal-to-Noise Ratio (SNR) | 100 dB |
| Crosstalk (1kHz) | 70 dB |
| Input sensitivity | 1400 mV |
| Input impedance | 50000 Ω |
| RMS rated power | 80 W |
| Frequency range | 20 - 20000 Hz |
| Speakers connectivity type | RCA |
|---|---|
| Line inputs (RCA) | 2 |
| Purpose | Home |
|---|---|
| Connectivity technology | Wired |
| Product colour | Black |
| Volume control | Rotary |
| On/off switch | Yes |
| Sustainability certificates | ENERGY STAR |
| Compliance certificates | RoHS |
| AC input voltage | 100 - 240 V |
|---|---|
| AC input frequency | 50 - 60 Hz |
| Width | 218.5 mm |
|---|---|
| Depth | 303.4 mm |
| Height | 43.3 mm |
| Weight | 3.1 kg |
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Certification | CE, FCC |
|---|
| Package weight | 4.5 kg |
|---|
