Harman

JBL CONTROL® SERIES 23-1 2-way Black 100 W

Part number CONTROL 23-1

2PK 3IN 2WAY SURFACE-MT SPKR PRICE PER PAIR

Contemporary, high-design appearance
Built-in InvisiBall® mounting hardware*, plus available U-bracket
Weather resistant enclosure and transducers
Wide 100° x 100° coverage
50 Watt power handling (100 Watt program) in direct 8Ω setting, plus built-in 15 Watt 70V/100V multi-tap transformer
High fidelity sound character with broad frequency response of 70 Hz – 20 kHz

Manufacturer: Harman
Part number: CONTROL 23-1
Condition: New
Category: Professional Sound › Pro Sound & ENT

Overview

The Control® 23-1 is a two-way 3” speaker with rich sonic character, wide coverage, consistent dispersion, versatile mounting, and a contemporary high-design look that fits into a wide range of decors. This makes Control 23-1 an excellent choice for a wide variety of applications, including retail stores, restaurants, health clubs, theme parks, educational facilities, hospitality, music cafes, leisure venues, and anywhere where a top quality compact indoor/outdoor foreground/background music (and/or paging) speaker is required.

Specifications

Loudspeakers
Speaker type	2-way
Number of drivers	2
Tweeter	Yes
Number of tweeter drivers	1
Tweeter diameter	1.3 cm
Tweeter diameter (imperial)	1.27 cm (0.5")
Woofer	Yes
Number of woofer drivers	1
Woofer diameter	7.6 cm
Woofer diameter (imperial)	7.62 cm (3")

Audio
RMS rated power	100 W
Peak Music Power Output (PMPO)	200 W
Frequency range	70 - 20000 Hz
Impedance	8 Ω
Sensitivity	86 dB
Sound pressure level (max)	103 dB

Performance
Recommended usage	Universal
Product colour	Black
Housing material	Polystyrene
International Protection (IP) code	IP44

Weight & dimensions
Width	141 mm
Depth	111 mm
Height	200 mm
Weight	1.8 kg

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
