Epson L690SE Short throw projector 6000 ANSI lumens WUXGA (1920x1200) White
Part number V11HB36020
EPSON POWERLITE L690SE SHORT-THROW (0.5 - 0.7 TR) LASER PROJECTOR WITH LENS SHIF
- Education Short throw projector White
- 6000 ANSI lumens
- Laser 20000 h
- WUXGA (1920x1200) 16:10 5000000:1
- Screen size compatibility: 2540 - 12700 mm (100 - 500") Number of colours: 1.07 billion colours
- Focus: Manual Zoom capability
- Ethernet LAN
- AC 432 W
- Manufacturer
- Epson
- Part number
- V11HB36020
- Condition
- New
- Category
- Presentation Devices › Projectors
- 1GPA category
- Hardware
Specifications
| Supported aspect ratios | 4:3, 16:10, 16:9, 16:6, 21:9 |
|---|---|
| Screen size compatibility | 2540 - 12700 mm (100 - 500") |
| Projection distance | 1.09 - 7.84 m |
| Projection distance (wide) | 1.1 - 5.6 m |
| Projection distance (tele) | 1.5 - 7.8 m |
| Projector brightness | 6000 ANSI lumens |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 5000000:1 |
| Native aspect ratio | 16:10 |
| Number of colours | 1.07 billion colours |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
| Matrix size | 1.7 cm (0.67") |
| Light source type | Laser |
|---|---|
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Focus | Manual |
|---|---|
| Focal length range | 7.54 - 10.55 mm |
| Aperture range (F-F) | 1.8 - 2 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Throw ratio | 0.50 - 1.70:1 |
| Horizontal lens shift range | -20 - 20% |
| Vertical lens shift range | -50 - 50% |
| Analog signal format system | Not supported |
|---|---|
| Full HD | Yes |
| 3D | No |
| Video colour modes | Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
| HDBaseT port | Yes |
|---|---|
| USB 2.0 Type-A ports quantity | 1 |
| USB 2.0 Type-B ports quantity | 1 |
| Serial interface type | RS-232C |
| HDMI ports quantity | 2 |
| DVI port | No |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
| Miracast | Yes |
| Card reader integrated | No |
|---|
| Interactive | No |
|---|---|
| Noise level (economic mode) | 26 dB |
| HDCP | Yes |
| Preset modes | Cinema, Dynamic, Presentation |
| Noise level | 36 dB |
| Market positioning | Education |
|---|---|
| Product type | Short throw projector |
| Product colour | White |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Power source | AC |
|---|---|
| Power consumption (typical) | 432 W |
| Power consumption (standby) | 0.3 W |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 100 - 240 V |
| Storage temperature (T-T) | -10 - 60 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 440 mm |
|---|---|
| Depth | 368 mm |
| Height | 151 mm |
| Weight | 9.3 kg |
| Remote control included | Yes |
|---|---|
| Batteries included | Yes |
| Warranty period | 3 year(s) |
|---|
