Epson EB-PQ2220B Large venue projector 20000 ANSI lumens 3LCD UHD 4K (3840x2160) Black
Part number V11HB05820
EPSON PROJECTOR EB-PQ2220B 20000LM 4K PROJECTOR BLA
- World's smallest and lightest 20,000-lumen 4K projector1
- 20,000 lumens of equal white and color brightness5
- 4K Crystal Motion technology
- Virtually maintenance-free 20,000-hour laser light source2
- High native contrast for a realistic display
- Manufacturer
- Epson
- Part number
- V11HB05820
- Condition
- New
- Category
- Presentation Devices › Projectors
- 1GPA category
- Hardware
Overview
The world’s smallest and lightest 20,000-lumen 4K projector.
The EB-PQ2220B large venue 4K laser projector features the latest Epson® technology—pioneering an unprecedented level of performance. The world’s smallest and lightest 20,000-lumen 4K projector1, the energy efficient EB-PQ2220B produces captivating visuals in extraordinary detail. Leveraging our 4K Crystal Motion technology, thermo-control panel and double micro-lens array, the EB-PQ2220B delivers stunning 4K resolution on-screen. With a high native contrast ratio and 3-chip 3LCD technology, you will enjoy a realistic display enriched with vibrant colors and deep blacks.
Designed for fixed installation applications and to meet the rigorous demands of live events, the EB-PQ2220B features a filterless cabinet, IP5X-rated hermetically sealed optical and light source unit, and a virtually maintenance-free 20,000-hour laser light source. The projector provides frame interpolation for fast-moving objects, as well as HDR support3 and scene adaptive gamma correction for lifelike images. The EB-PQ2220B pairs with 9 optional powered lenses (sold separately) to simplify installation and includes a host of premium features for fast setup, such as built-in NFC functionality, and an optional attachable PixAlign™ camera to streamline multi-projector setups.
Specifications
| Supported aspect ratios | 16:9, 21:9 |
|---|---|
| Smart projector | No |
| Projector brightness | 20000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | UHD 4K (3840x2160) |
| Contrast ratio (typical) | 5000000:1 |
| Native aspect ratio | 16:9 |
| Number of colours | 1.07 billion colours |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -45 - 45° |
| White light output | 20000 ANSI lumens |
| Colour light output | 20000 ANSI lumens |
| Light source type | Laser |
|---|---|
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Focal length range | 14.8 – 17 |
|---|---|
| Aperture range (F-F) | 2 - 2.1 |
| Zoom capability | Yes |
| Zoom ratio | 1.6:1 |
| Throw ratio | 1.52 – 2.47 |
| Analog signal format system | Not supported |
|---|---|
| Full HD | Yes |
| 3D | No |
| Video colour modes | Cinema, Dynamic, Natural, Presentation |
| HDBaseT port | Yes |
|---|---|
| Service port type | USB Type-B |
| USB 2.0 Type-A ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Serial interface type | RS-232C |
| HDMI ports quantity | 3 |
| DVI port | No |
| AC (power) in | Yes |
| Smart TV | No |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi | No |
| Card reader integrated | No |
|---|
| Interactive | No |
|---|---|
| Noise level (economic mode) | 39 dB |
| HDCP | Yes |
| On Screen Display (OSD) | Yes |
| Noise level | 48 dB |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG) |
| International Protection (IP) code | IPX5 |
| Password protection | Yes |
| Market positioning | Presentation |
|---|---|
| Product type | Large venue projector |
| Product colour | Black |
| Placement | Ceiling, Desktop, Floor, Flying frame, Wall |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Built-in display | No |
|---|---|
| Colour depth | 10 bit |
| Power source | AC |
|---|---|
| Power consumption (typical) | 1431 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (economy mode) | 975 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Operating temperature (T-T) | 0 - 50 °C |
|---|
| Width | 586 mm |
|---|---|
| Depth | 492 mm |
| Height | 185 mm |
| Weight | 29.2 kg |
| Remote control included | Yes |
|---|---|
| Batteries included | Yes |
| Cables included | AC |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
