Overview
This design changes everything
Epson® professional photo and graphics printers built around our revolutionary PrecisionCore® MicroTFP printhead technology have set the benchmark for high-end print quality. With the SureColor® P8570DL, Epson brings that same technology to high-speed production, photo and graphic art printing—with an equally extraordinary design. Featuring the smallest footprint in its class1 and all-front-operation, this high-performance printer fits where other printers can’t. Its innovative 6-color aqueous-pigment ink set delivers the widest color gamut in its class2. This printer pairs simple, carefree operation with new levels of versatility and media flexibility, as well as a dual-roll configuration, to help you do more with less—all with a low total cost of ownership. Add it all up, and this is not just a one-of-a-kind printer—it’s a powerful option for high-volume shops and fleets. The SureColor P8570DL uses 6-color UltraChrome® PRO6 Ink with Gray and a high-capacity 1.6-liter ink pack system to produce vivid, beautiful output that rivals comparable 8-color printers.
Specifications
Printing
| Print technology | Inkjet |
|---|
| Colour | Yes |
|---|
| Maximum resolution | 2400 x 1200 DPI |
|---|
| Number of print cartridges | 6 |
|---|
| Page description languages | ESC P, PostScript 3, PDF 1.7 |
|---|
| Printing colours | Cyan, Magenta, Yellow, Matte black, Photo black, Grey |
|---|
Paper handling
| Paper tray media types | Roll |
|---|
| Cut sheets | Yes |
|---|
| Media thickness | 0.07 - 0.08 mm |
|---|
| Maximum roll length | 272.4 m |
|---|
Ports & interfaces
| Wi-Fi | Yes |
|---|
| Ethernet LAN | Yes |
|---|
| USB port | Yes |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
|---|
Performance
| Product colour | Black, White |
|---|
| Built-in display | Yes |
|---|
| Display diagonal | 10.9 cm (4.3") |
|---|
| Control type | Touch |
|---|
Power
| Power consumption (typical) | 70 W |
|---|
| Power consumption (off) | 0.3 W |
|---|
| AC input voltage | 110 - 240 V |
|---|
| AC input frequency | 50/60 Hz |
|---|
Operational conditions
| Operating temperature (T-T) | 10 - 35 °C |
|---|
| Operating relative humidity (H-H) | 20 - 80% |
|---|
| Storage temperature (T-T) | -20 - 40 °C |
|---|
| Storage relative humidity (H-H) | 5 - 85% |
|---|
Weight & dimensions
| Width | 1854.2 mm |
|---|
| Depth | 498 mm |
|---|
| Height | 975.4 mm |
|---|
| Weight | 165.1 kg |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
