Overview
Powerful impact printers built for busy print environments.
The Epson LQ-590II Impact Printer offers the durability and ease of use for critical daily print requirements. These reliable 24-pin impact printers boast a long life cycle, a 3-year limited warranty and speeds up to 584 cps. Their up-to-5-million-character ribbon cartridge reduces user interventions as well as cost per page. Engineered for seamless integration into virtually any system, they include Epson ESC/P2® and IBM® PPDS printer languages. Ideal for harsh environments, these workhorses race through cut-sheet, continuous or multipart forms up to 7 pages thick, and feature an intuitive control panel for easy setup and operation.
Specifications
Printing
| Maximum printing width (columns) | 80 |
|---|
| Colour | No |
|---|
| Maximum print speed | 550 cps |
|---|
| Character pitch | 10 cpi |
|---|
| Built-in barcodes | Code 128 (A/B/C), Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E |
|---|
| Character sets | ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8 |
|---|
Paper handling
| Paper tray media types | Envelopes, Labels, Plain paper, Roll |
|---|
| Cut sheet thickness range | 0.065 - 0.49 mm |
|---|
| Continuous paper thickness range | 0.065 - 0.49 mm |
|---|
Features
| Product colour | Black |
|---|
| Buffer size | 128 KB |
|---|
| Sound pressure level (printing) | 55 dB |
|---|
Ports & interfaces
| Standard interfaces | Parallel, USB 2.0 |
|---|
Endurance
| Print head | 24-pin |
|---|
| Print head life | 400 million characters |
|---|
| Ribbon life | 5 million characters |
|---|
| Mean time between failures (MTBF) | 25000 h |
|---|
Power
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|
| Operating relative humidity (H-H) | 10 - 80% |
|---|
System requirements
| Windows operating systems supported | Yes |
|---|
Weight & dimensions
| Width | 437 mm |
|---|
| Depth | 375 mm |
|---|
| Height | 177 mm |
|---|
| Weight | 7.2 kg |
|---|
Technical details
| Number of pins | 24 |
|---|
| Sustainability certificates | ENERGY STAR |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
