Overview
Professional-quality large-format scanning.
Take large-format photo and graphics scanning to a new level with the Epson Expression® 13000XL. Engineered for demanding applications such as photo archiving and graphic arts, this powerful scanner uses the latest technology to truly capture your originals—a 2400 x 4800 dpi resolution and optical density of 3.8 Dmax allow for clean, sharp images; additionally, Epson MatrixCCD® and ReadyScan® LED technologies plus 48-bit color depth deliver brilliant, vibrant colors with incredible accuracy. The Epson Expression 13000XL brings exceptional versatility to the table, accommodating reflective and other media types up to 12.2" x 17.2". Add on Epson’s optional Transparency Unit (sold separately) to easily scan film and other transparent materials up to 12" x 16.5". One-touch color restoration using Easy Photo Fix® technology, batch scanning, and powerful LaserSoft Imaging SilverFast Ai scanning and image processing software help enhance your productivity and expand the limits of what a professional scanner can do.
Specifications
Scanning
| Maximum scan size | 310 x 437 mm |
|---|
| Optical scanning resolution | 2400 x 4800 DPI |
|---|
| Duplex scanning | No |
|---|
| Input colour depth | 48 bit |
|---|
| Output colour depth | 48 bit |
|---|
| Input greyscale depth | 16 bit |
|---|
| Output greyscale depth | 16 bit |
|---|
Design
| Scanner type | Flatbed scanner |
|---|
| Product colour | White |
|---|
| Built-in display | No |
|---|
Performance
| Sensor type | CCD |
|---|
| Light source | ReadyScan LED |
|---|
Paper handling
| Maximum ISO A-series paper size | A3 |
|---|
Ports & interfaces
| USB port | Yes |
|---|
| USB version | 2.0 |
|---|
Power
| Power supply type | AC |
|---|
| Power consumption (typical) | 27 W |
|---|
| AC input frequency | 50/60 Hz |
|---|
| Input voltage | 120 - 220 V |
|---|
Weight & dimensions
| Width | 656 mm |
|---|
| Depth | 458 mm |
|---|
| Height | 158 mm |
|---|
| Weight | 14.3 kg |
|---|
System requirements
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP |
|---|
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
|---|
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 R2 |
|---|
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|
| Storage temperature (T-T) | -25 - 60 °C |
|---|
| Operating relative humidity (H-H) | 10 - 80% |
|---|
| Storage relative humidity (H-H) | 10 - 85% |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
