Overview
The lightweight portable scanner engineered for business.
The smallest and lightest mobile single-sheet-fed document scanner1, the Epson DS-70 features fast speeds for busy professionals ― scanning a single page in as fast as 5.5 seconds2. This portable scanner accommodates documents up to 8.5" x 72", plus business/ID cards and receipts. Included OCR and document management software allows users to easily create editable text and searchable PDFs. No batteries or external power are required when the scanner is connected to a computer via the USB port. Compatible with both Windows® and Mac®, the DS-70 is ideal for virtually any workspace. And, it’s backed by a 3-year limited warranty3.
Specifications
Scanning
| Maximum scan size | 216 x 356 mm |
|---|
| Optical scanning resolution | 600 x 600 DPI |
|---|
| Colour scanning | Yes |
|---|
| Duplex scanning | No |
|---|
| Input greyscale depth | 16 bit |
|---|
| Output monochrome depth | 8 bit |
|---|
| ADF scan speed (b/w, A4) | 10 ppm |
|---|
Design
| Scanner type | Sheet-fed scanner |
|---|
| Product colour | Black, White |
|---|
| Built-in display | No |
|---|
Performance
| Sensor type | Colour CIS |
|---|
| Light source | RGB LED |
|---|
| Daily duty cycle (max) | 300 pages |
|---|
| Scan drivers | TWAIN |
|---|
Input capacity
| Auto document feeder (ADF) input capacity | 1 sheets |
|---|
Paper handling
| Maximum ISO A-series paper size | A4 |
|---|
| Auto Document Feeder (ADF) media weight | 35 - 270 g/m² |
|---|
Ports & interfaces
| USB port | Yes |
|---|
| USB version | 2.0 |
|---|
| Standard interfaces | USB 2.0 |
|---|
Power
| Power supply type | USB |
|---|
| Power consumption (typical) | 2.5 W |
|---|
| Sleep mode | Yes |
|---|
| Power consumption (sleep) | 1 W |
|---|
Weight & dimensions
| Width | 272 mm |
|---|
| Depth | 47 mm |
|---|
| Height | 34 mm |
|---|
| Weight | 270 g |
|---|
Packaging content
| Cables included | USB |
|---|
| Bundled software | Epson Scan 2
Document Capture Pro (Windows)
Document Capture (Mac) |
|---|
System requirements
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP |
|---|
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
|---|
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|
| Storage temperature (T-T) | -25 - 60 °C |
|---|
Other features
| Compliance certificates | RoHS |
|---|
Logistics data
| Country of origin | China |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
