EnGenius SN-UL-AK20L-IND network antenna N-type 2.7 dBi
Part number SN-UL-AK20L-IND
INDOOR CEILING MOUNT EXT ANT W 20M CABLE
- N-type White
- 2.7 dBi
- 0.863 - 093 GHz
- 50 Ω
- Vertical polarization Female
- Ceiling
- Manufacturer
- EnGenius
- Part number
- SN-UL-AK20L-IND
- Condition
- New
- Category
- Accessories › Phone & Cellular Accessories
- 1GPA category
- Hardware
Overview
The SN-UL-AK20L-IND is a 900MHz external antenna kit which connects to base stations for EnGenius DuraFon or FreeStyl phone systems. Includes 20-meters of LMR-400 cable.
Optimal radiation pattern provides the best indoor coverage.
High quality low loss LMR-400 cable ensures minimal attenuation of the received and transmitted signal.
Specifications
| Frequency band | 0.863 - 093 GHz |
|---|---|
| Impedance | 50 Ω |
| Horizontal beam width | 83° |
| Vertical beam width | 83° |
| Antenna gain level (max) | 2.7 dBi |
| Antenna connector type | N-type |
|---|---|
| Connector gender | Female |
| Polarization | Vertical polarization |
| Voltage Standing Wave Ratio (VSWR) | 2.0:1 |
| Product colour | White |
| Power handling | 10 W |
| Cable length | 20 m |
| Mounting | Ceiling |
| Purpose | Indoor |
| Operating temperature (T-T) | -20 - 65 °C |
|---|
| Height | 108 mm |
|---|---|
| Diameter | 17 cm |
| Weight | 320 g |
| Quantity per pack | 1 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
