Overview
The EOC655-C23, an Outdoor 5GHz Dual Radio 2x2 Access Point with an 23 dBi Panel Antenna, is tailored for ISPs and Smart Cities. It delivers superior throughput in dense RF environments and is versatile for both PtP and PtMP applications. Simplified setup and troubleshooting are facilitated by a 2.4GHz radio and mobile app integration. Featuring built-in GPS for precise device placement and network mapping, it also includes IP67-rated durability and 'dying gasp' power failure detection. With AES-256 encryption for security and SkyPoint NMS for web-based management, the EOC655-C23 excels in performance and ease of use.
Specifications
Features
| 2.4 GHz | Yes |
|---|
| 5 GHz | No |
|---|
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
|---|
| Ethernet LAN data rates | 10,100,1000,25000 Mbit/s |
|---|
| Frequency band | 5.1 - 5.9 GHz |
|---|
| Networking standards | IEEE 802.11ax |
|---|
| Bluetooth | Yes |
|---|
| Channel bandwidth | 160 MHz |
|---|
| MIMO | Yes |
|---|
| MIMO type | Multi User MIMO |
|---|
| VLAN support | Yes |
|---|
| Virtual LAN features | Tagged VLAN |
|---|
| Dynamic Frequency Selection (DFS) | Yes |
|---|
| Quality of Service (QoS) support | Yes |
|---|
| BeamForming | Yes |
|---|
Security
| Security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, SSH |
|---|
| MAC address filtering | Yes |
|---|
| IP address filtering | Yes |
|---|
| Service Set Identifier (SSID) features | Multiple SSIDs |
|---|
| IGMP snooping | Yes |
|---|
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
|---|
Management features
| Syslog | Yes |
|---|
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 |
|---|
Power
| Power over Ethernet (PoE) | Yes |
|---|
| Power consumption (max) | 25 W |
|---|
Design
| Placement | Ceiling, Wall |
|---|
| Product colour | White |
|---|
| International Protection (IP) code | IP67 |
|---|
Antenna
| Antenna type | Internal |
|---|
| Antenna direction type | Omni-directional |
|---|
| Antenna features | Integrated antenna |
|---|
| Antennas quantity | 3 |
|---|
| Antenna gain level (max) | 23 dBi |
|---|
| Antenna connector type | N-type |
|---|
Performance
| Built-in processor | Yes |
|---|
| Processor model | ARM Cortex-A53 |
|---|
| Flash memory | 32 MB |
|---|
| Internal memory | 1000 MB |
|---|
Certificates
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), Industry Canada (IC), RoHS, UKCA, WEEE |
|---|
| Certification | CE, FCC |
|---|
Weight & dimensions
| Width | 305 mm |
|---|
| Depth | 305 mm |
|---|
| Height | 82 mm |
|---|
| Weight | 1.91 kg |
|---|
Packaging data
| Package width | 365 mm |
|---|
| Package depth | 166 mm |
|---|
| Package height | 512 mm |
|---|
| Package weight | 4.68 kg |
|---|
Packaging content
| Quantity per pack | 1 pc(s) |
|---|
| PoE adapter included | Yes |
|---|
| Mounting kit | Yes |
|---|
Operational conditions
| Operating relative humidity (H-H) | 0 - 90% |
|---|
| Operating temperature (T-T) | -10 - 60 °C |
|---|
| Storage temperature (T-T) | -30 - 80 °C |
|---|
| Storage relative humidity (H-H) | 0 - 90% |
|---|
Logistics data
| Harmonized System (HS) code | 85176990 |
|---|
| Master (outer) case width | 354 mm |
|---|
| Master (outer) case length | 390 mm |
|---|
| Master (outer) case height | 552 mm |
|---|
| Master (outer) case gross weight | 9.99 kg |
|---|
| Products per master (outer) case | 2 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
