EnGenius

EnGenius Cloud Managed AP Indoor Dual Band 11ax 1148+2400Mbps 4T4R 2.5GbE PoE.at(+) 5dBi ea

Part number ECW270

ENGENIUS CLOUD-MNGD ECW270 AP OUTDOOR WI-FI 6 4X4 ACCESS POINT

Dual concurrent 802.11ax & backward-compatible with 11ac/a/b/g/n client devices
Supports up to 2,400 Mbps in 5 GHz band & 1,200 Mbps in 2.4 GHz band
IP68-Rated weatherproof & dustproof housing withstands harsh environments
1 x 2.5 Giga PoE++ compatible port realizes greater throughput and supports Power over Ethernet (802.3 at/bt) for flexible installation over 100 meters (328 feet)
1 x Gigabit Port
Four detachable 5 dbi high-gain 2.4GHz antennas
Four detachable 7 dbi high-gain 5GHz antennas
Quick-scan device register & configuration and remote monitoring & troubleshooting
Cloud manage an unlimited number of APs from anywhere with the EnGenius Cloud App
Mesh Wireless Support simplifies setup, optimizes signals & self-heals

Manufacturer: EnGenius
Part number: ECW270
Condition: New
Category: Network Devices › Wireless Networking
1GPA category: Hardware

Overview

EnGenius Cloud Managed Wi-Fi 6 4x4 Access Point ECW270 supports dual concurrent 802.11ax with backward compatibility, providing up to 2,400 Mbps in the 5 GHz band and 1,200 Mbps in the 2.4 GHz band. Its IP68-rated weatherproof and dustproof housing withstands harsh environments, and its Mesh Wireless Support simplifies setup and self-heals. The EnGenius Cloud App allows remote management of an unlimited number of APs.

Specifications

Features
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	2400 Mbit/s
Maximum data transfer rate (2.4 GHz)	1200 Mbit/s
Maximum data transfer rate (5 GHz)	2400 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
MIMO	Yes
MIMO type	Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes

Security
Security algorithms	WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise, WPA3-PSK
MAC address filtering	Yes

Ports & interfaces
Ethernet LAN (RJ-45) ports	2

Power
Power over Ethernet (PoE)	Yes

Design
Placement	Pole, Wall
Product colour	White
International Protection (IP) code	IP68
LED indicators	Yes

Antenna
Antenna type	External
Antenna connector type	N-type

Performance
Built-in processor	Yes
Processor frequency	2200 MHz

Weight & dimensions
Width	218 mm
Depth	285 mm
Height	55.5 mm
Weight	1.87 kg

Packaging data
Package width	370 mm
Package depth	146 mm
Package height	305 mm
Package weight	4.37 kg

Packaging content
Quantity per pack	1 pc(s)

Operational conditions
Operating relative humidity (H-H)	0 - 90%
Operating temperature (T-T)	-20 - 65 °C
Storage temperature (T-T)	-30 - 80 °C
Storage relative humidity (H-H)	0 - 90%

Logistics data
Harmonized System (HS) code	85176990
Master (outer) case width	320 mm
Master (outer) case length	390 mm
Master (outer) case height	340 mm
Master (outer) case gross weight	9.8 kg
Products per master (outer) case	2 pc(s)
