EnGenius
EnGenius Cloud Managed AP Outdoor Dual Band 11ax 574+1200Mbps 2T2R 2.5GbE PoE.at(+) 4x5dBi RP-SMA IP67
Part number ECW260
ENGENIUS CLOUD MANAGED ECW260 OUTDOOR WIFI 6 WIRELESS AP
- Dual concurrent 802.11ax & backward-compatible with 11ac/a/b/g/n client devices
- Supports up-to 1,200 Mbps in 5-GHz band & 574 Mbps in 2.4-GHz band
- IP67-Rated weatherproof & dustproof housing withstands harsh environments
- 2.5 GigE PoE+ compatible port for easy placement where power outlets are scarce
- Four (4) (2x2) detachable 5dbi high-gain, 360° SMA-type antennas
- Quick-scan device register & configuration and remote monitoring & troubleshooting
- Cloud manage unlimited number of APs from anywhere with the EnGenius Cloud App
- Mesh Wireless Support simplifies setup, optimizes signals & self-heals
- Manufacturer
- EnGenius
- Part number
- ECW260
- Condition
- New
- Category
- Network Devices › Wireless Networking
- 1GPA category
- Hardware
Overview
EnGenius Cloud Managed ECW260 Outdoor Wi-Fi 6, 2x2, IP67, MU-MIMO Dual-Band Access Point reaches speeds of 1,200 Mbps on 5GHz and 574 Mbps on 2.4GHz band. This top-of-the-line cloud-managed AP features the latest in rugged weatherproofing and Wi-Fi 6 technology with guaranteed top-notch performance and reliability in the harshest environments.
Specifications
| 2.4 GHz | Yes |
|---|---|
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate | 1774 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1200 Mbit/s |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3af, IEEE 802.3at |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Spread spectrum method | DSSS |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Quality of Service (QoS) support | Yes |
| BeamForming | Yes |
| Security algorithms | SNMP, SNMPv2, SNMPv3, WPA2-AES, WPA2-Enterprise, WPA3-Enterprise, WPA3-PSK |
|---|---|
| MAC address filtering | Yes |
| Service Set Identifier (SSID) features | Hidden SSID, Multiple SSIDs |
| Number of SSID supported | 8 |
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Power over Ethernet (PoE) | Yes |
|---|---|
| Power over Ethernet (PoE) type supported | Active PoE |
| Power consumption (max) | 15.9 W |
| Placement | Pole, Wall |
|---|---|
| Product colour | White |
| International Protection (IP) code | IP67 |
| LED indicators | LAN, Power, WLAN |
| Antenna type | External |
|---|---|
| Antenna direction type | Omni-directional |
| Antenna features | Detachable antenna |
| Antennas quantity | 4 |
| Antenna gain level (max) | 5 dBi |
| Antenna connector type | SMA |
| Built-in processor | Yes |
|---|---|
| Processor model | ARM Cortex-A53 |
| Processor frequency | 1800 MHz |
| Certification | FCC, CE, IC |
|---|
| Width | 124 mm |
|---|---|
| Depth | 190 mm |
| Height | 52.5 mm |
| Weight | 700 g |
| Package width | 284 mm |
|---|---|
| Package depth | 144 mm |
| Package height | 234 mm |
| Package weight | 1.51 kg |
| Quantity per pack | 1 pc(s) |
|---|---|
| Mounting kit | Yes |
| Quick start guide | Yes |
| Antenna included | Yes |
| Operating temperature (T-T) | -20 - 60 °C |
|---|---|
| Storage temperature (T-T) | -40 - 80 °C |
| Harmonized System (HS) code | 85176990 |
|---|---|
| Master (outer) case width | 450 mm |
| Master (outer) case length | 490 mm |
| Master (outer) case height | 310 mm |
| Master (outer) case gross weight | 11.9 kg |
| Products per master (outer) case | 6 pc(s) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
