Overview
The Cloud Managed 4K AI Outdoor Dome without MicroSD Card (ECC500Z) is a cloud-managed surveillance solution for SMBs seeking scalable security. It enables seamless remote monitoring via the cloud dashboard and mobile app. This camera can integrate with EnGenius NVS for durable and reliable video recording. Enhanced with an 8MP Sony Starvis sensor with HDR and an extended IR range, it delivers exceptional image clarity in all lighting conditions. IP67 and IK10-rated, it is built to withstand harsh environments. Advanced AI technology, including facial recognition, tracks unusual person in real time, triggering instant alerts and enabling AI-powered searches to reduce footage review time from hours to minutes.
Specifications
Performance
| Type | IP security camera |
|---|
| Placement supported | Indoor |
|---|
| Connectivity technology | Wired |
|---|
| Day/night mode | Yes |
|---|
| Infrared (IR) cut-off filter | Yes |
|---|
Design
| Form factor | Dome |
|---|
| Mounting type | Ceiling |
|---|
| Product colour | White |
|---|
| Housing material | Aluminium |
|---|
| International Protection (IP) code | IP67 |
|---|
| IK code | IK10 |
|---|
| Country of origin | Taiwan |
|---|
Camera
| Camera pan control | Yes |
|---|
| Camera tilt control | Yes |
|---|
| Angle of rotation | 350° |
|---|
| Lens viewing angle, horizontal | 30.3 - 108.1° |
|---|
| Lens viewing angle, vertical | 17.1 - 56.3° |
|---|
| Lens viewing angle, diagonal | 34.8 - 130.9° |
|---|
| Tilt angle range | 0 - 60° |
|---|
| Pan range | 0 - 350° |
|---|
Image sensor
| Number of sensors | 1 |
|---|
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
|---|
| Sensor type | CMOS |
|---|
Lens system
| Zoom capability | Yes |
|---|
| Number of lenses | 1 |
|---|
Night vision
| Night vision | Yes |
|---|
| Night vision distance | 30 m |
|---|
Video
| Maximum resolution | 3840 x 2160 pixels |
|---|
| Total megapixels | 8 MP |
|---|
| Video formats supported | H.264, H.265 |
|---|
| Video compression formats | H.264, H.265 |
|---|
| Supported graphics resolutions | 3840 x 2160 |
|---|
| Supported video modes | 2160p |
|---|
| Video recording | Yes |
|---|
| Frame rate | 20 fps |
|---|
Audio
| Audio formats supported | AAC, G.711 |
|---|
| Built-in microphone | Yes |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Wi-Fi | No |
|---|
| Bluetooth | No |
|---|
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
|---|
Management features
| Cloud-managed | Yes |
|---|
| Reset button | Yes |
|---|
Power
| Power source type | PoE |
|---|
| Power consumption (max) | 16.1 W |
|---|
Operational conditions
| Operating temperature (T-T) | -40 - 60 °C |
|---|
| Operating relative humidity (H-H) | 5 - 90% |
|---|
Weight & dimensions
| Height | 105 mm |
|---|
| Diameter | 14.5 cm |
|---|
| Weight | 740 g |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
