Overview
The EnGenius Cloud Camera Cam5MP Dome (ECC100Z) is a cloud-managed outdoor surveillance solution for SMBs seeking scalable security. It enables seamless remote monitoring via the cloud dashboard and mobile app. This camera can backup video to EnGenius NVS for reliable HD video recording. Enhanced with a 5MP Sony Starvis sensor with HDR, a 132° viewing angle, and a 20m IR range, it delivers clear imaging in all lighting conditions. IP67 and IK10-rated, it is built to withstand harsh environments. Advanced AI technology detects unusual people and vehicles in real time, triggering instant alerts and enabling AI-powered searches to reduce footage review time from hours to minutes.
Specifications
Performance
| Type | IP security camera |
|---|
| Placement supported | Indoor |
|---|
| Connectivity technology | Wired |
|---|
| Day/night mode | Yes |
|---|
| Infrared (IR) cut-off filter | Yes |
|---|
Design
| Form factor | Dome |
|---|
| Mounting type | Ceiling |
|---|
| Product colour | White |
|---|
| LED indicators | Yes |
|---|
| International Protection (IP) code | IP67 |
|---|
| IK code | IK10 |
|---|
| Country of origin | Taiwan |
|---|
Camera
| Camera pan control | Yes |
|---|
| Camera tilt control | Yes |
|---|
| Angle of rotation | 350° |
|---|
| Lens viewing angle, horizontal | 102° |
|---|
| Lens viewing angle, vertical | 71.6° |
|---|
| Lens viewing angle, diagonal | 132° |
|---|
| Tilt angle range | 0 - 90° |
|---|
| Pan range | 0 - 350° |
|---|
Image sensor
| Number of sensors | 1 |
|---|
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
|---|
| Sensor type | CMOS |
|---|
Lens system
| Number of lenses | 1 |
|---|
Night vision
| Night vision | Yes |
|---|
| Night vision distance | 20 m |
|---|
| LED type | IR |
|---|
Video
| Maximum resolution | 2592 x 1944 pixels |
|---|
| Total megapixels | 5 MP |
|---|
| Video formats supported | H.264, H.265 |
|---|
| Video compression formats | H.264, H.265 |
|---|
| Supported graphics resolutions | 2592 x 1944 |
|---|
| Supported video modes | 1944p |
|---|
| Video recording | Yes |
|---|
| Frame rate | 20 fps |
|---|
Audio
| Audio formats supported | AAC, G.711 |
|---|
| Built-in microphone | Yes |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Wi-Fi | No |
|---|
| Bluetooth | No |
|---|
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
|---|
Management features
| Cloud-managed | Yes |
|---|
Power
| Power source type | PoE |
|---|
| Power consumption (max) | 6.5 W |
|---|
Operational conditions
| Operating temperature (T-T) | -20 - 50 °C |
|---|
| Operating relative humidity (H-H) | 0 - 98% |
|---|
Weight & dimensions
| Height | 94.8 mm |
|---|
| Diameter | 12.2 cm |
|---|
| Weight | 525 g |
|---|
Packaging content
| Number of cameras | 1 |
|---|
