EnGenius
EnGenius Managed Dome IP Camera
Part number ECC100
ENGENIUS CLOUD AI CAMERA ECC100 5MP HDR 132DEG 20M IR 256GB IP67
- Cloud Managed Dome AI Camera is accessible anytime from anywhere
- Clear day-and-night visuals with 5MP HDR Clarity, powered by a Sony Starvis sensor
- 132° ultra-wide view and 20m IR long-distance coverage for versatile environments
- 24/7 Continuous event recording, with convenient 256GB built-in storage
- Indoor/outdoor durable IP67 weatherproof and IK10 vandal-resistant build
- AI Cloud analytics uses multimodal analysis to detect complex scenarios in real-time
- Natural language search via advanced AI multimodal large language models (LLMs)
- Cloud-AI alerts notify you of events like bullying, accidents, and weapon detection
- Cloud Edge AI Camera with NPU for real-time detection, lightweight metadata
- Eliminate NVRs: Integrated storage for better video retention and instant access
- Optional AI-Powered NVS: RAID-backed redundancy enhances camera systems with AI
- Surveillance AI cameras for student housing, senior living, multi-family units, hospitality, and assisted living
- Manufacturer
- EnGenius
- Part number
- ECC100
- Condition
- New
- Category
- Physical Security › Video Surveillance
- 1GPA category
- Hardware
Overview
The EnGenius ECC100 Indoor/Outdoor 5MP Dome AI Camera with 132° ultra-wide view, 20-meter IR, IP67 outdoor rating, IK10 durability, and built-in 256GB storage. The AI Cloud and Edge analytics detect complex scenarios and provide instant alerts, enabling advanced surveillance in MDU, hospitality, and assisted living environments.
Specifications
| Type | IP security camera |
|---|---|
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Built-in processor | Yes |
| Form factor | Dome |
|---|---|
| Mounting type | Ceiling |
| Product colour | White |
| International Protection (IP) code | IP67 |
| IK code | IK10 |
| Angle of rotation | 350° |
|---|---|
| Lens viewing angle, horizontal | 102° |
| Lens viewing angle, vertical | 71.6° |
| Lens viewing angle, diagonal | 132° |
| Tilt angle range | 0 - 90° |
| Pan range | 0 - 350° |
| Camera shutter speed | 1/7.5 - 1/10000 s |
| Number of sensors | 1 |
|---|---|
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Sensor type | CMOS |
| Number of lenses | 1 |
|---|---|
| Maximum aperture number | 2 |
| Fixed focal length | 3.16 mm |
| Night vision | Yes |
|---|---|
| Night vision distance | 20 m |
| LED type | IR |
| Maximum resolution | 2592 x 1944 pixels |
|---|---|
| Total megapixels | 5 MP |
| Video formats supported | H.264, H.265 |
| Video compression formats | H.264, H.265 |
| Supported video modes | 1944p |
| Video recording | Yes |
| Frame rate | 20 fps |
| Video streaming | Yes |
| Audio formats supported | AAC, G.711 |
|---|---|
| Built-in microphone | Yes |
| Ethernet LAN | Yes |
|---|---|
| Ethernet interface type | Fast Ethernet |
| Wi-Fi | No |
| Bluetooth | No |
| ROM capacity | 256000 MB |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Video motion detection | Yes |
|---|---|
| Human and vehicle targets classification | Yes |
| Cloud-managed | Yes |
|---|
| Power source type | PoE |
|---|---|
| Power consumption (max) | 6.1 W |
| Operating temperature (T-T) | -20 - 50 °C |
|---|---|
| Operating relative humidity (H-H) | 0 - 95% |
| Height | 94.8 mm |
|---|---|
| Diameter | 12.2 cm |
| Weight | 525 g |
| Package width | 216 mm |
|---|---|
| Package depth | 186 mm |
| Package height | 143 mm |
| Package weight | 1.02 kg |
| Number of cameras | 1 |
|---|
| Master (outer) case width | 396 mm |
|---|---|
| Master (outer) case length | 456 mm |
| Master (outer) case height | 476 mm |
| Master (outer) case gross weight | 13.6 kg |
| Products per master (outer) case | 12 pc(s) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
