Eizo
EIZO RadiForce MX317W computer monitor 77.5 cm (30.5") 4096 x 2160 pixels 4K DCI LCD Black
Part number MX317W-BK
MX-SERIES 30.5IN LCD LED COLOR DICOM CALIB BLK INTEG FRONT SENSOR
- 77.5 cm (30.5") Black
- Height adjustment 10 cm
- USB upstream port type: USB Type-B, USB Type-C HDMI DisplayPorts quantity: 1
- Screen shape: Flat
- Response time: 25 ms
- 4096 x 2160 pixels 4K DCI Panel type: IPS
- Manufacturer
- Eizo
- Part number
- MX317W-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Specifications
| Display diagonal | 77.5 cm (30.5") |
|---|---|
| Display resolution | 4096 x 2160 pixels |
| HD type | 4K DCI |
| Native aspect ratio | 17:9 |
| Display technology | LCD |
| Panel type | IPS |
| LED backlight | Yes |
| Touchscreen | No |
| Display brightness (typical) | 550 cd/m² |
| Response time | 25 ms |
| Screen shape | Flat |
| Contrast ratio (typical) | 1800:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.1674 x 0.1674 mm |
| Viewable size, horizontal | 68.6 cm |
| Viewable size, vertical | 36.2 cm |
| Digital horizontal frequency | 31 - 134 kHz |
| Digital vertical frequency | 59 - 61 Hz |
| Display diagonal (metric) | 77.5 cm |
| Colour depth | 13 bit |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Built-in speaker(s) | No |
|---|---|
| Built-in camera | No |
| Market positioning | Medical |
|---|---|
| Product colour | Black |
| Feet colour | Black |
| Built-in USB hub | Yes |
|---|---|
| USB upstream port type | USB Type-B, USB Type-C |
| Number of USB Type-B upstream ports quantity | 2 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 3 |
| USB Type-C downstream ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 94 W |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Headphone out | No |
| Built-in KVM switch | Yes |
| Ethernet LAN | Yes |
|---|
| VESA mounting | Yes |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Height adjustment | Yes |
| Adjustable height (max) | 10 cm |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | 5 - 30° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Swedish |
| Energy efficiency class (SDR) | Not available |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Power consumption (typical) | 62 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 260 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Width (with stand) | 721 mm |
|---|---|
| Depth (with stand) | 225.1 mm |
| Height (with stand) | 469.5 mm |
| Weight (with stand) | 12.4 kg |
| Width (without stand) | 721 mm |
| Depth (without stand) | 73 mm |
| Height (without stand) | 401 mm |
| Weight (without stand) | 8.2 kg |
| Cables included | AC, DisplayPort, HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C |
|---|---|
| Quick start guide | Yes |
| Manual | Yes |
| Certification | CE (Medical Device), UKCA (Medical Device), ANSI/AAMI ES60601-1, CSA C22.2 Nr. 601-1, EN60601-1, IEC60601-1, CB, RCM, FCC-B, CAN ICES-3 (B), VCCI-B, RoHS, WEEE, China RoHS, CCC |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
