EIZO DuraVision FDF2712W-IP computer monitor 68.6 cm (27") 1920 x 1080 pixels Full HD LCD Black
Part number FDF2712W-IP-BK
DURAVISION 27 IP MONITOR W/BUIL DURAVISION 27 IP MONITOR W/BUILT-IN
- Connection of IP surveillance cameras and IP video streaming without PC
- Powerful decoding technology for up to 48 streams
- Alert-to-Action - targeted and quickly in the picture
- Easy configuration via the web interface and API
- Live data protection
- Camera protocol support: ONVIF, Panasonic/iPro and Axis VAPIX
- RTSP control support
- HDMI output for second Full HD monitor
- Manufacturer
- Eizo
- Part number
- FDF2712W-IP-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
Computerless, the DuraVision FDF2712W-IP displays video streams transmitted over the network. Neither software nor other hardware is required for the full HD decoding monitor. This means easy installation, little maintenance and little time and effort. The IP decoder platform of the 27"" monitor decodes H.265 (HEVC), H.264 and MJPEG codecs in real time. The advantage: high frame rates - even when streaming high-resolution videos over multiple channels. Even 16 simultaneous full HD video feeds (1920 × 1080)
run at a stable frame rate of 20 fps (frames per second). Up to 48 IP cameras can be registered to the DuraVision FDF2712W-IP with support for RTSP as well as ONVIF Profile S, Axis VAPIX and Panasonic/iPro protocols. The easy-to-use web interface allows users to conveniently adjust the arrangement of video streams and view up to 32 streams simultaneously. An HDMI output allows the connection of a second monitor with a resolution up to Full HD, which can then also be used for IP video feeds via FDF2712W-IP.
Specifications
| Display diagonal | 68.6 cm (27") |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Panel type | VA |
| Touchscreen | No |
| Display brightness (typical) | 350 cd/m² |
| Response time | 12 ms |
| Screen shape | Flat |
| Contrast ratio (typical) | 3000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.311 x 0.311 mm |
| Viewable size, horizontal | 59.8 cm |
| Viewable size, vertical | 33.6 cm |
| Display diagonal (metric) | 68.6 cm |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Built-in speaker(s) | No |
|---|---|
| Built-in camera | No |
| Market positioning | Industrial |
|---|---|
| Product colour | Black |
| Feet colour | Black |
| Built-in USB hub | Yes |
|---|---|
| USB Type-A downstream ports quantity | 2 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| Headphone out | Yes |
| Headphone connectivity | 3.5 mm |
| Ethernet LAN | Yes |
|---|
| VESA mounting | Yes |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Height adjustment | Yes |
| Adjustable height (max) | 15 cm |
| Swivelling | Yes |
| Swivel angle range | 0 - 344° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| Power consumption (standby) | 0.5 W |
|---|---|
| Power consumption (max) | 59 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Width (with stand) | 640 mm |
|---|---|
| Depth (with stand) | 245 mm |
| Height (with stand) | 404.5 mm |
| Weight (with stand) | 9.9 kg |
| Width (without stand) | 640 mm |
| Depth (without stand) | 65 mm |
| Height (without stand) | 379 mm |
| Weight (without stand) | 7.1 kg |
| Cables included | Power |
|---|---|
| Quick start guide | Yes |
| RJ-45 ports quantity | 1 |
|---|---|
| Certification | CE, UKCA, CB, RCM, cTÜVus, FCC-A, CAN ICES-3 (A), TÜV/S, PSE, VCCI-A, RoHS, WEEE, China RoHS, CCC, BIS |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
