EIZO FlexScan EV4340X-BK computer monitor 108 cm (42.5") 3840 x 2160 pixels 4K Ultra HD LCD Black
Part number EV4340X-BK
4K ULTRA-SLIM FRAME DESIGN 42.5IN WIDE SCRN TFT IPS LCD
- 42.5" monitor with large display, 4K resolution and 104 ppi
- Signal inputs: USB-C (DisplayPort Alt Mode), display port, 2 x HDMI
- Picture-by-picture for 4 signal sources and picture-in-picture for 2 signal sources
- KVM switch function for 2 signal sources
- Docking function via USB-C with DisplayPort signal, LAN and power supply up to 94 watts
- Optionally in black or white housing color
- Contrast 1000:1, brightness 350 cd/m², 178° viewing angle
- Auto EcoView and EcoView Optimizer for maximum energy savings and optimum ergonomics
- Demonstrably environmentally conscious and socially responsible production
- 5-year warranty for maximum investment security
- Manufacturer
- Eizo
- Part number
- EV4340X-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
With a 42.5 inch screen diagonal, the EIZO FlexScan EV4340X is ideal for use in control rooms, control centers, trading floors or similar work environments: Its 4K resolution (3840 x 2160 pixels) offers four times as much information as a Full HD monitor. In addition to two HDMI inputs and a DisplayPort connection, the monitor has full USB-C docking functionality including DisplayPort Alt Mode, transmission of video, audio and USB data signals and a power supply of up to 94 watts. The EV4340X also masters operation with multiple computers or image sources with ease. The integrated KVM switch allows the use of a keyboard and mouse combination on two computers. Thanks to its picture-in-picture (PbP) function, the monitor can display up to four video signals side by side. The button on the front can be used to conveniently switch between 12 available layouts. The picture-in-picture (PiP) function for two signal sources offers efficient screen utilization for presentations and meetings. These and other important functions can be controlled on the monitor or via the supplied remote control. Therefore, the EIZO FlexScan EV4340X is also well suited for wall mounting when buttons on the device are not accessible. Its slim design makes grouping in multi-screen systems particularly easy.
Specifications
| Display diagonal | 108 cm (42.5") |
|---|---|
| Display resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Touchscreen | No |
| Display brightness (typical) | 350 cd/m² |
| Response time | 5 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160 |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.245 x 0.245 mm |
| Pixel density | 104 ppi |
| Viewable size, horizontal | 94.1 cm |
| Viewable size, vertical | 52.9 cm |
| Digital horizontal frequency | 31 - 134 kHz |
| Digital vertical frequency | 29 - 61 Hz |
| Display diagonal (metric) | 108 cm |
| Colour gamut standard | sRGB |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
| Number of speakers | 2 |
|---|---|
| RMS rated power | 8 W |
| Built-in speaker(s) | Yes |
| Built-in camera | No |
| Market positioning | Office |
|---|---|
| Product colour | Black |
| Feet colour | Silver |
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B, USB Type-C |
| Number of upstream ports | 1 |
| Number of USB Type-B upstream ports quantity | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 2 |
| USB Type-C downstream ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 94 W |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| DisplayPorts quantity | 1 |
| Headphone out | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| Built-in KVM switch | Yes |
| HDCP | Yes |
| HDCP version | 1.4/2.3 |
| Ethernet LAN | Yes |
|---|
| VESA mounting | Yes |
|---|---|
| Panel mounting interface | 100 x 100,200 x 200 mm |
| Height adjustment | No |
| Picture-in-Picture | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Swedish |
| Energy efficiency class (SDR) | E |
|---|---|
| Energy consumption (SDR) per 1000 hours | 31 kWh |
| Power consumption (typical) | 31 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (max) | 243 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency scale | A to G |
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width (with stand) | 966.8 mm |
|---|---|
| Depth (with stand) | 225.3 mm |
| Height (with stand) | 631 mm |
| Weight (with stand) | 15.9 kg |
| Width (without stand) | 966.8 mm |
| Depth (without stand) | 89.9 mm |
| Height (without stand) | 571 mm |
| Weight (without stand) | 15.2 kg |
| Stand included | Yes |
|---|---|
| Cables included | AC, DisplayPort, USB Type-A to USB Type-B, USB Type-C to USB Type-C |
| Remote control included | Yes |
| Quick start guide | Yes |
| Sustainability compliance | Yes |
|---|---|
| Sustainability certificates | ENERGY STAR, EPEAT Climate +, EPEAT Silver, TCO |
| Warranty period | 5 year(s) |
|---|---|
| Picture-by-Picture (PbP) | Yes |
| Automatic brightness control | Yes |
| Look-up table (LUT) bit depth | 14 |
| Compliance certificates | CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TÜV mark, UKCA, VCCI |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Certification | CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EPEAT 2018 Silver (US), EPEAT Climate + |
| Harmonized System (HS) code | 85285210 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
