EIZO FlexScan EV3450XC-BK computer monitor 86.6 cm (34.1") 3440 x 1440 pixels UltraWide Quad HD LCD Black
Part number EV3450XC-BK
34.1 ULTRA-WIDE CURVED 3800R TF ULTRA-SLIM FRAME DESIGN 34.1 ULTRA-
- 34.1"" curved ultrawide monitor with 21:9 format and 3440x1440 pixels (109 ppi) for excellent readability
- 5 MP webcam, microphone with noise canceling, integrated speaker and audio connection
- Docking function via USB-C with DisplayPort signal, LAN and power supply up to 94 watts
- Signal inputs: USB-C (DisplayPort Alt Mode), DisplayPort, dual HDMI
- Auto EcoView, EcoView Index and EcoView Optimizer for maximum energy savings and optimum ergonomics
- KVM switch and picture-in-picture operation for up to 2 computers/signal sources
- Optionally in black or white housing color
- Demonstrably environmentally conscious and socially responsible production
- 5-year warranty for maximum investment security
- Manufacturer
- Eizo
- Part number
- EV3450XC-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
The EIZO FlexScan EV3450XC is optimized for the demands of the modern working world. With an integrated, high-resolution 5MP webcam, built-in microphone with noise and echo cancellation and feedback-free speakers, it is fully equipped for video conferencing. In addition, the curved ultrawide screen with a 34.1" diagonal, 21:9 format and UWQHD resolution (3440 x 1440 pixels) offers an extra large screen area for demanding applications or intensive multitasking. The webcam and infrared sensor support Windows Hello for convenient and secure unlocking of the computer using facial recognition. The EV3450XC’s USB-C docking connects video, audio and USB data signals and charges laptops with 94 watts of power. The integrated LAN port enables stable online conferences. Image reproduction with the EV3450XC is sharp, clear, fast and flicker-free. When scrolling and positioning windows or images, the readable display appears in fractions of a second - faster than it can be perceived. Power consumption and energy efficiency are always in view. This also applies to colors, which are displayed in sRGB free of oversaturation. Equipped in this way, the EV3450XC is ideally tailored to the challenges of companies that rely on hybrid forms of work with a combination of office work and remote work.
Specifications
| Display diagonal | 86.6 cm (34.1") |
|---|---|
| Display resolution | 3440 x 1440 pixels |
| HD type | UltraWide Quad HD |
| Native aspect ratio | 21:9 |
| Display technology | LCD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Touchscreen | No |
| Display brightness (typical) | 300 cd/m² |
| Response time | 5 ms |
| Anti-glare screen | Yes |
| Screen shape | Curved |
| Screen curvature rating | 3800R |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3440 x 1440 |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.233 x 0.233 mm |
| Pixel density | 109 ppi |
| Viewable size, horizontal | 80 cm |
| Viewable size, vertical | 33.5 cm |
| Digital horizontal frequency | 31 - 89.5 kHz |
| Digital vertical frequency | 29.5 - 61 Hz |
| Display diagonal (metric) | 86.7 cm |
| Colour gamut standard | sRGB |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
| Number of speakers | 2 |
|---|---|
| RMS rated power | 8 W |
| Built-in speaker(s) | Yes |
| Megapixel (approx.) | 5 MP |
| Built-in microphone | Yes |
| Built-in camera | Yes |
| Market positioning | Office |
|---|---|
| Product colour | Black |
| Feet colour | Black |
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B, USB Type-C |
| Number of upstream ports | 2 |
| Number of USB Type-B upstream ports quantity | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 2 |
| USB Type-C downstream ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 94 W |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| DisplayPorts quantity | 1 |
| Headphone out | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| Built-in KVM switch | Yes |
| HDCP | Yes |
| HDCP version | 1.4/2.3 |
| Ethernet LAN | Yes |
|---|
| VESA mounting | Yes |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Height adjustment | Yes |
| Adjustable height (max) | 19.5 cm |
| Swivelling | Yes |
| Swivel angle range | -90 - 90° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Swedish |
| Energy efficiency class (SDR) | F |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 25 kWh |
| Power consumption (typical) | 23 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (max) | 222 W |
| Power consumption (off) | 0 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency scale | A to G |
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width (with stand) | 819.5 mm |
|---|---|
| Depth (with stand) | 242 mm |
| Height (with stand) | 414.5 mm |
| Weight (with stand) | 12.1 kg |
| Width (without stand) | 819.5 mm |
| Depth (without stand) | 103.1 mm |
| Height (without stand) | 385 mm |
| Weight (without stand) | 9.2 kg |
| Stand included | Yes |
|---|---|
| Cables included | AC, DisplayPort, USB Type-C to USB Type-C, USB Type-A to USB Type-B |
| Quick start guide | Yes |
| Sustainability compliance | Yes |
|---|---|
| Sustainability certificates | ENERGY STAR, EPEAT Climate +, EPEAT Gold, TCO |
| Warranty period | 5 year(s) |
|---|---|
| Picture-by-Picture (PbP) | Yes |
| Automatic brightness control | Yes |
| Look-up table (LUT) bit depth | 14 |
| Compliance certificates | CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), GS mark, PSE, RCM, RoHS, TÜV mark, UKCA, VCCI |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Certification | CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 10, TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, China RoHS, CCC, EPEAT 2018 Gold (US), EPEAT Climate + |
| Harmonized System (HS) code | 85285210 |
|---|
