Eizo
EIZO ColorEdge CS2731 computer monitor 68.6 cm (27") 2560 x 1440 pixels Quad HD LCD Black
Part number CS2731-BK
27IN WS LCD 2560X1440 1000:1 S2731-BK USB HDMI DP BLACK 10MS
- 27-inch wide gamut LCD with 2560 x 1440 pixels (WQHD) to deliver ultra-sharp details
- EIZO microchip ensures precise, consistent and lasting colour display
- Wide gamut covering 99% of the Adobe RGB colour gamut
- Precise hardware calibration of brightness, white balance and gamma
- Digital Uniformity Equaliser for top-rate luminance distribution and colour purity
- Colour precision ensured via 16-bit look-up-table and up to 10-bit colour reproduction
- USB-C (DisplayPort signal channel and power supply up to 60 W), DisplayPort, DVI-D and HDMI ports
- USB hub with two USB 3.1 and two USB 2.0 downstream ports
- ColorNavigator calibration software available for free download
- Recommended optional accessories: measuring device for hardware calibration and monitor hood
- Manufacturer
- Eizo
- Part number
- CS2731-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
The CS2731 unites precision, colour fidelity and cutting-edge connectivity thanks to its USB-C port. This makes the monitor the central interface for the graphic workflow of sophisticated creatives with high standards. The wide gamut, 16-bit look-up-table and precise factory calibration of the CS2731 allows you to enjoy an unadulterated look at your image files in creative workflows requiring high colour accuracy. Convenient functionalities such as monitor signal transmission, rapid data transfer and the power supply feature for connected devices are enabled with just one USB-C port.
Specifications
| Display diagonal | 68.6 cm (27") |
|---|---|
| Display resolution | 2560 x 1440 pixels |
| HD type | Quad HD |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Touchscreen | No |
| Display brightness (typical) | 350 cd/m² |
| Response time | 16 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Supported graphics resolutions | 2560 x 1440, 1920 x 1200 (WUXGA) |
| Supported video modes | 1080p, 1080i, 720p, 576p, 576i, 480p, 480i |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.233 x 0.233 mm |
| Pixel density | 109 ppi |
| Viewable size, horizontal | 59.7 cm |
| Viewable size, vertical | 33.6 cm |
| Digital horizontal frequency | 15 - 89 kHz |
| Digital vertical frequency | 23 - 61 Hz |
| Colour depth | 10 bit |
| Colour gamut standard | Adobe RGB, DCI-P3, sRGB |
| sRGB coverage (typical) | 100% |
| Adobe RGB coverage | 99% |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Flicker-free technology | Yes |
| Built-in speaker(s) | No |
|---|---|
| Built-in camera | No |
| Market positioning | Photo editing |
|---|---|
| Product colour | Black |
| Feet colour | Black |
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B, USB Type-C |
| Number of upstream ports | 2 |
| Number of USB Type-B upstream ports quantity | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 4 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 60 W |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Built-in KVM switch | Yes |
| HDCP | Yes |
| VESA mounting | Yes |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 15.5 cm |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Swivelling | Yes |
| Swivel angle range | 0 - 344° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| On Screen Display (OSD) | Yes |
| Energy efficiency class (SDR) | G |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 35.7 kWh |
| Power consumption (typical) | 35.7 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 159 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width (with stand) | 638 mm |
|---|---|
| Depth (with stand) | 265 mm |
| Height (with stand) | 404.1 mm |
| Weight (with stand) | 10.1 kg |
| Width (without stand) | 638 mm |
| Depth (without stand) | 75 mm |
| Height (without stand) | 378.2 mm |
| Weight (without stand) | 6.5 kg |
| Stand included | Yes |
|---|---|
| Cables included | AC, HDMI, USB Type-C to USB Type-C |
| Quick start guide | Yes |
| Hardware calibration | Yes |
|---|---|
| Warranty period | 5 year(s) |
| Look-up table (LUT) bit depth | 16 |
| Compliance certificates | RoHS |
| Certification | CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241- 307), cTÜVus, TÜV/S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE |
| Native refresh rate | 60 Hz |
|---|
| Harmonized System (HS) code | 85285210 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
