EIZO ColorEdge CS2400S-BK computer monitor 61.2 cm (24.1") 1920 x 1200 pixels WUXGA LCD Black
Part number CS2400S-BK
24IN WIDE SCREEN WIDE COLOR GAMUT TFT IPS LCD LED BACKLIGHT
- 24" Wide Gamut LCD with 1920 x 1200 pixels, 16:10 format
- Wide colour gamut with 99% AdobeRGB and 95% DCI-P3 colour space coverage
- 410 cd/m² maximum brightness, contrast 1350:1
- 10-bit display, 16-bit look-up table
- Exact hardware calibration of brightness, white point and gamma
- Digital Uniformity Equalizer for perfect luminance distribution and colour purity
- USB-C (DisplayPort signal and up to 70 Watt Power Delivery), DisplayPort and HDMI input
- USB hub with two 5Gbps (USB 3) and two USB 2 downstream ports
- Manufacturer
- Eizo
- Part number
- CS2400S-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
The ColorEdge CS2400S is the perfect entry into the world of maximum precision: the panel offers extremely wide coverage of the relevant colour spaces (e.g. 99 % AdobeRGB). The Digital Uniformity Equalizer (DUE) ensures homogeneous image representation and the 16-bit look-up table guarantees absolutely precise colour representation with up to 10 bits. On the one hand, the exact factory calibration guarantees the highest precision "out of the box". On the other hand, the regularly recommended recalibration is done in no time at all. This means that photographers, filmmakers or image editors can always rely on their monitor to show them an absolutely precise view of their image file. The docking functions via USB-C allow the image signal to be transferred and the monitor’s USB hub to be powered with just one cable. In addition, a mobile device can be supplied with up to 70 watts of charging current. In this way, the CS2400S becomes the central dock of the creative workflow with a flick of the wrist. Alternatively, the monitor can of course also be operated via HDMI or DisplayPort as well as USB-B upstream.
Specifications
| Display diagonal | 61.2 cm (24.1") |
|---|---|
| Display resolution | 1920 x 1200 pixels |
| HD type | WUXGA |
| Native aspect ratio | 16:10 |
| Display technology | LCD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Touchscreen | No |
| Display brightness (typical) | 410 cd/m² |
| Response time | 19 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Supported graphics resolutions | 1920 x 1200 (WUXGA), 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p, 1080i, 720p, 576p, 576i, 480p, 480i |
| Contrast ratio (typical) | 1350:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.27 x 0.27 mm |
| Pixel density | 94 ppi |
| Horizontal scan range | 15 - 76 kHz |
| Vertical scan range | 23 - 61 Hz |
| Viewable size, horizontal | 51.8 cm |
| Viewable size, vertical | 32.4 cm |
| Display diagonal (metric) | 61.1 cm |
| Colour depth | 10 bit |
| Colour gamut standard | Adobe RGB, DCI-P3, sRGB |
| sRGB coverage (typical) | 100% |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Flicker-free technology | Yes |
| Built-in speaker(s) | No |
|---|---|
| Built-in camera | No |
| Market positioning | Photo editing |
|---|---|
| Product colour | Black |
| Feet colour | Black |
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B, USB Type-C |
| Number of upstream ports | 2 |
| Number of USB Type-B upstream ports quantity | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 4 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 70 W |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Built-in KVM switch | Yes |
| HDCP | Yes |
| HDCP version | 2.3 |
| VESA mounting | Yes |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Height adjustment | Yes |
| Adjustable height (max) | 15.5 cm |
| Pivot | Yes |
| Pivot angle | 0 - 90° |
| Swivelling | Yes |
| Swivel angle range | 0 - 344° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| On Screen Display (OSD) | Yes |
| Energy efficiency class (SDR) | E |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 16 kWh |
| Power consumption (typical) | 18 W |
| Power consumption (standby) | 0.3 W |
| Power consumption (max) | 149 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width (with stand) | 554.4 mm |
|---|---|
| Depth (with stand) | 245 mm |
| Height (with stand) | 396 mm |
| Weight (with stand) | 8.2 kg |
| Width (without stand) | 554.4 mm |
| Depth (without stand) | 64 mm |
| Height (without stand) | 362 mm |
| Weight (without stand) | 5.2 kg |
| Stand included | Yes |
|---|---|
| Cables included | AC, HDMI, USB Type-C to USB Type-C |
| Quick start guide | Yes |
| Hardware calibration | Yes |
|---|---|
| Warranty period | 5 year(s) |
| Look-up table (LUT) bit depth | 16 |
| Compliance certificates | CB, CCC, CE, China Compulsory Certification (CCC), Federal Communications Commission (FCC), PSE, RoHS, cTUVus, UKCA, WEEE |
| Certification | CE, UKCA, CB, TÜV/GS, TÜV Ergonomie geprüft (einschließlich ISO 9241-307), RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, RoHS, WEEE, China RoHS, CCC |
| Harmonized System (HS) code | 85285210 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
