EIZO ColorEdge CG2400S computer monitor 61.2 cm (24.1") 1920 x 1200 pixels WUXGA LCD Black
Part number CG2400S-IEC-BK
SLIM FRAME DESIGN 24IN WIDE SCREEN WIDE COLOR GAMUT TFT IPS
- 24-inch Wide Gamut LCD with 1920 x 1200 pixels, 16:10 format
- Wide color gamut with 99% Adobe RGB and 98% DCIP3 color space coverage
- 400 cd/m² maximum brightness, 1800:1 contrast
- 10-bit display, 16-bit 3D Look-Up-Table
- Integrated calibration sensor for fully automatic self-calibration
- Digital Uniformity Equalizer for perfect luminance distribution and color purity
- USB-C (DisplayPort signal and up to 70 watts Power Delivery), DisplayPort and HDMI input
- USB hub with four USB downstream ports, two of which are 5Gbps (USB 3) and two USB 2
- Light protection cover included in the scope of delivery
- 5-year warranty for highest investment security
- Manufacturer
- Eizo
- Part number
- CG2400S-IEC-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
With its wide color gamut, enormous 1800:1 contrast ratio, state-of-the-art USB-C connectivity and pre-installed HDR presets, the CG2400S is the ideal tool for professional creatives. The CG2400S with Wide Gamut IPS panel, 10-bit color depth and 16-bit 3D Look-Up-Table (LUT) offers perfect precision, smooth color transitions and nuances. The Adobe RGB color space is covered by 99% and the DCI-P3 color space by 98%. Thanks to the presets for HLG and the PQ gamma curves, even the smallest model in the ColorEdge CG series can be ideally integrated into HDR production workflows. The integrated calibration sensor enables effortless, automatic calibration. Thanks to the universal connectivity via USB-C, a single cable is used to transmit the image signal and power the monitor’s USB hub. It can also be used to supply a mobile device with up to 70 watts of charging current. In combination with the integrated USB hub, the CG2400S becomes the central dock for creative workflows in a single operation. Of course, an HDMI and DisplayPort connection are also on board. The supplied light protection screen rounds off the CG2400S’s extensive features.
Specifications
| Display diagonal | 61.2 cm (24.1") |
|---|---|
| Display resolution | 1920 x 1200 pixels |
| HD type | WUXGA |
| Native aspect ratio | 16:10 |
| Display technology | LCD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Touchscreen | No |
| Display brightness (typical) | 400 cd/m² |
| Response time | 11 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
| Supported video modes | 1080p, 1080i, 720p, 576p, 576i, 480i, 480p |
| Contrast ratio (typical) | 1800:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.27 x 0.27 mm |
| Pixel density | 94 ppi |
| Viewable size, vertical | 51.8 cm |
| Viewable size diagonal | 32.4 cm |
| Digital horizontal frequency | 15 - 76 kHz |
| Digital vertical frequency | 23 - 61 Hz |
| Display diagonal (metric) | 61 cm |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | Hybrid Log-Gamma (HLG) |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Flicker-free technology | Yes |
| Built-in speaker(s) | No |
|---|---|
| Built-in camera | No |
| Market positioning | Photo editing |
|---|---|
| Product colour | Black |
| Feet colour | Black |
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B, USB Type-C |
| Number of upstream ports | 2 |
| Number of USB Type-B upstream ports quantity | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 4 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 70 W |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Built-in KVM switch | Yes |
| HDCP | Yes |
| VESA mounting | Yes |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 15.5 cm |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Swivelling | Yes |
| Swivel angle range | 0 - 344° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Swedish |
| Energy efficiency class (SDR) | E |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 16 kWh |
| Power consumption (typical) | 17 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 150 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width (with stand) | 554.4 mm |
|---|---|
| Depth (with stand) | 245 mm |
| Height (with stand) | 408.1 mm |
| Weight (with stand) | 8.5 kg |
| Width (without stand) | 554.4 mm |
| Depth (without stand) | 70.2 mm |
| Height (without stand) | 374.1 mm |
| Weight (without stand) | 5.5 kg |
| Stand included | Yes |
|---|---|
| Cables included | HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C, AC |
| Sun hood included | Yes |
| Quick start guide | Yes |
| Hardware calibration | Yes |
|---|---|
| Built-in calibration sensor | Yes |
| Warranty period | 5 year(s) |
| Look-up table (LUT) bit depth | 16 |
| Compliance certificates | CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), PSE, RCM, RoHS, TÜV mark, UKCA, VCCI, WEEE, cTUVus |
| Certification | CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, RoHS, WEEE, China RoHS, CCC |
| Native refresh rate | 60 Hz |
|---|
| Harmonized System (HS) code | 85285210 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
