EIZO ColorEdge CG1-BK computer monitor 77.5 cm (30.5") 4096 x 2160 pixels 4K DCI LCD Black
Part number CG1-BK
GRADE 1 REFERENCE MONITOR 30.5INDCI-4K WIDE COLOR GAMUT DUAL-
- 30.5-inch Wide Gamut LCD with 4096 x 2160 pixels (DCI-4K)
- HDR brightness and dynamic range calibrated to 1000 nits and reference class 1 level
- Deep black with up to 1000000:1 contrast - without ABL or local dimming
- HDR-HLG and HDR-PQ-EOTF precisely calibrated to reference class 1 level
- Calibrated presets for: BT.2020, BT.709, DCI-P3, PQ_BT.2100, PQ_DCI-P3, PQ_Theater, HLG_BT2100
- SDI connections: Single-Link 12G/6G/3G/HD-SD, Dualand Quad-Link 3G (2 sample interleave) SFT28 connections (25GbE, ST 2110) for IP-based production environments
- HDMI with FRL - supports 12 bit 4:4:4 in DCI 4K resolution
- DisplayPort - up to 10 bit 4:4:4
- 5-year guarantee for maximum investment security
- Manufacturer
- Eizo
- Part number
- CG1-BK
- Condition
- New
- Category
- Displays › Computer Monitors
- 1GPA category
- Hardware
Overview
The ColorEdge PROMINENCE CG1 is EIZO’s professional reference monitor for color grading and mastering professional HDR and SDR film content. The unique combination of extreme contrast range, huge color space coverage, razor-sharp image display and outstanding precision make it a reliable precision tool for film post-production in the film and television industry. With connections such as SDI, ST2110, HDMI (incl. FRL) and DisplayPort, the PROMINENCE CG1 can be seamlessly integrated into any production environment. The integrated calibration sensor simplifies recalibration enormously and enables automated quality management.
Specifications
| Display diagonal | 77.5 cm (30.5") |
|---|---|
| Display resolution | 4096 x 2160 pixels |
| HD type | 4K DCI |
| Native aspect ratio | 17:9 |
| Display technology | LCD |
| Panel type | IPS |
| Backlight type | W-LED |
| Touchscreen | No |
| Display brightness (peak) | 1000 cd/m² |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.167 x 0.167 mm |
| Pixel density | 152 ppi |
| Viewable size, horizontal | 68.6 cm |
| Viewable size, vertical | 36.2 cm |
| Digital horizontal frequency | 25 - 137 kHz |
| Digital vertical frequency | 23 - 61 Hz |
| Display diagonal (metric) | 77.5 cm |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | Hybrid Log-Gamma (HLG) |
| DCI-P3 coverage | 100% |
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Built-in speaker(s) | No |
|---|---|
| Built-in camera | No |
| Market positioning | Graphics design |
|---|---|
| Product colour | Black |
| Feet colour | Black |
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| Number of USB Type-B upstream ports quantity | 2 |
| USB Type-A downstream ports quantity | 3 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
| BNC input ports | 4 |
| VESA mounting | Yes |
|---|---|
| Height adjustment | No |
| On Screen Display (OSD) | Yes |
| Power consumption (typical) | 271 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 420 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Width (with stand) | 746.8 mm |
|---|---|
| Depth (with stand) | 208 mm |
| Height (with stand) | 482.7 mm |
| Weight (with stand) | 17.5 kg |
| Width (without stand) | 746.8 mm |
| Depth (without stand) | 165.8 mm |
| Height (without stand) | 457 mm |
| Weight (without stand) | 16.8 kg |
| Cables included | HDMI, USB Type-A to USB Type-B, DisplayPort, Power |
|---|
| RJ-45 ports quantity | 1 |
|---|---|
| Certification | CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), RCM, cTÜVus, FCC-A, CAN ICES-3 (A), TÜV/S, PSE, VCCI-A, RoHS, WEEE |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
