Eaton 93PX5KA uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 5000 W 2 AC outlet(s)
Part number 93PX5KA
93PX 5000VA 5000W 208V 3-PHASE ONLINE DOUBLE-CONVERSION UPS BUNDLE - L21-30P INP
- Innovative quick-connect design for easy plug-and-play deployment and service
- Corded AC input and output for convenient utility power and PDU connections
- Unity power factor (1.0) and high power density to save data center white space
- Cybersecure network card enables full remote access and control 24/7
- Maintenance bypass keeps equipment operational during UPS service or replacement
- Manufacturer
- Eaton
- Part number
- 93PX5KA
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
93PX 5000VA 5000W 208V 3-Phase Online Double-Conversion UPS Bundle - L21-20P Input, 2x L21-20R Output, Maintenance Bypass, Cybersecure Network Card, Extended Run, 9U, TAA
Specifications
| UPS topology | Double-conversion (Online) |
|---|---|
| Output power capacity | 5 kVA |
| Output power | 5000 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 120 V |
| Input operation voltage (max) | 208 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 208 V |
| Output frequency | 50/60 Hz |
| Response time | 10 ms |
| Number of input phases | 3 |
| Number of output phases | 3 |
| Input power factor | 1 |
| Crest factor | 3:1 |
| AC outlet types | NEMA L21-20 |
|---|---|
| AC outlets quantity | 2 AC outlet(s) |
| Battery technology | Sealed Lead Acid (VRLA) |
|---|---|
| Battery life (max) | 6 year(s) |
| Form factor | Rackmount |
|---|---|
| Rack capacity | 9U |
| Product colour | Black |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Compliance certificates | TAA |
|---|
| Width | 437.9 mm |
|---|---|
| Depth | 805.4 mm |
| Height | 391.9 mm |
| Weight | 129.5 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
