Eaton 93PX20KHWPAR uninterruptible power supply (UPS) Double-conversion (Online) 20 kVA 20000 W

Part number 93PX20KHWPAR

20KW PARALLEL 208V 3-PH UPS HARDWIRED AND NETWORK-M3 CARDS

Innovative quick-connect design for easy plug-and-play deployment and service
Up to 97% energy efficiency in ECO mode to save energy and operating costs
Unity power factor (1.0) and high power density to save data center white space
Cybersecure network cards allow full UPS remote access and control 24/7
Parallel maintenance bypass panel enables N+1 redundancy to maintain uptime

Manufacturer: Eaton
Part number: 93PX20KHWPAR
Condition: New
Category: Power & Rack Equipment › Power Equipment
1GPA category: Hardware

Overview

93PX 20000VA 20000W N+1 208V 3-Phase Online Double-Conversion UPS - Hardwired Input/Output, Maintenance Bypass, Cybersecure Network Cards, Extended Run, 21U

Specifications

Features
UPS topology	Double-conversion (Online)
Output power capacity	20 kVA
Output power	20000 W
Waveform	Pure sine
Input operation voltage (min)	120 V
Input operation voltage (max)	208 V
Input frequency	50/60 Hz
Output operation voltage (min)	120 V
Output operation voltage (max)	208 V
Response time	10 ms
Number of input phases	3
Number of output phases	3
Input power factor	1
Output power factor	1
Crest factor	3:1

Ports & interfaces
AC outlet types	Hardwire
Power plug	Hardwire

Battery
Battery technology	Sealed Lead Acid (VRLA)
Battery life (max)	6 year(s)

Design
Form factor	Rackmount
Rack capacity	21U
Product colour	Black

Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 60 °C
Operating relative humidity (H-H)	0 - 95%

Certificates
Compliance certificates	UL

Weight & dimensions
Width	438 mm
Depth	819.2 mm
Height	914.4 mm
Weight	412.5 kg

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
