Eaton 93PX15KHWIND uninterruptible power supply (UPS) Double-conversion (Online) 15 kVA

Part number 93PX15KHWIND

EATON 93PX 15000VA 15000W 208V 3-PHASE ONLINE UPS HARDWIRED INPUT/OUTPUT MAINTEN

Innovative quick-connect design for easy plug-and-play deployment and service
Up to 97% energy efficiency in ECO mode to save energy and operating costs
Unity power factor (1.0) and high power density to save data center white space
Cybersecure network card enables full remote access and control 24/7
Maintenance bypass keeps equipment operational during UPS service or replacement

Manufacturer: Eaton
Part number: 93PX15KHWIND
Condition: New
Category: Power & Rack Equipment › Power Equipment
1GPA category: Hardware

Overview

93PX 15000VA 15000W 208V 3-Phase Online Double-Conversion UPS - Hardwired Input/Output, Maintenance Bypass, Cybersecure Industrial Gateway Card, Extended Run, 12U (93PX15KHWIND)

Specifications

Features
UPS topology	Double-conversion (Online)
Output power capacity	15 kVA
Waveform	Pure sine
Input operation voltage (min)	120 V
Input operation voltage (max)	208 V
Input frequency	50/60 Hz
Output frequency	60 Hz
Output voltage regulation	1%
Maximum current	60 A
Number of input phases	3
Number of output phases	3
Input power factor	1
Output power factor	1
Crest factor	3:1

Ports & interfaces
Power plug	Hardwire

Battery
Battery technology	Sealed Lead Acid (VRLA)
Battery life (max)	6 year(s)

Design
Form factor	Rackmount
Rack capacity	12U
Product colour	Black

Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 60 °C
Operating relative humidity (H-H)	0 - 95%

Technical details
Network management	Yes
Battery included	Yes

Weight & dimensions
Width	438 mm
Depth	819.1 mm
Height	522.5 mm
Weight	211 kg

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
